8 4 R E V O L U T I O N W I R E L E S S ™
1 0 . e M c t a B l e S
10 . 3 rec o mm e n d e d se p ar a ti o n d i st a nc e s
recOMMe Nded SPaci NG Be tWe eN a PO rtaBle a Nd M OBile cOM MuN ic atiO N
deVice aNd tHe de Vi ce
The device is designed for use in an electromagnetic environment in which radiated RF waves are
controlled. The buyer or user of the device can contribute to preventing electromagnetic interference
by maintaining a minimum distance between portable and mobile RF communication devices
(transmitters) and the device according to the table of recommendations below and according to the
maximum output power of the telecommunication device.
Maximum Spacing according to the frequency of the transmitter m
transmitter
From 150 kHz to 80 MHz
output power
d = 1.2 √P
W
0.01 0.12
0.1 0.38
1 1.2
10 3.8
100 12
In the case of transmitters whose maximum output power is not shown in the table above, the
recommended spacing of d in meters (m) can be calculated using the appropriate equation for the
transmitter frequency, where P is the maximum output power of the transmitter in watts (W) as set by
the transmitter manufacturer
NOTE 1 At 80 MHz and at 800 MHz ,the spacing for high frequency amplitude is applied.
NOTE 2 These guidelines may not be appropriate for some situations. Electromagnetic wave
propagation is modified by absorption and reflection due to buildings, objects and persons.
1 1 . c O N t a c t
We would be happy to answer any questions you may have about our products and services.
Please contact your local dealer, or your corresponding DJO Global site.
DJO Global sites are listed on the backside of the cover.
For technical service from DJO Global, please contact:
chattproductsupport@djoglobal.com
Chattanooga Product Support: (800) 494-3395
From 80 kHz to 800 MHz
d = 1.2 √P
0.12
0.38
1.2
3.8
12
E N
From 800 MHz to 2.5 GHz
d = 2.3 √P
0.23
0.73
2.3
7.3
23
