1 0. 2 ele ct r o mag n e t i c i mm u n i t y
r e cOMMe N dati ONS aN d dec l arati O N By tH e MaN uFac turer
cO Ncer N iNG el ectr OMaG Neti c iM MuN it y
Device is designed for use in the electromagnetic environment stipulated below. The buyer or user of
the device must ensure it is used in this recommended environment.
im muni ty test
Electrostatic
discharge (ESD)
IEC 61000-4-2
Fast transient
electrical bursts
IEC 61000-4-4
Surge (1)
IEC 61000-4-5
tes t lev el ie c O bs e r v ance
60601 lev e l
±6 kV at the ±6 kV at the
contact contact
±8 kV in air ±8 kV in air
±2 kV for power 2 kV for power
supply lines supply lines
±1 kV for Not applicable
input/output lines (I/O lines)
±1 kV differential
±1 kV differential
mode
mode
Not applicable
±2 kV joint mode
(line to earth)
electromag neti c envi ronm e nt -
rec ommendations
Floors must be wood, concrete or
ceramic tile.
If floors are covered with synthetic
material the relative humidity must be
maintained at a minimum of 30%.
The Revolution Wireless device may be
susceptible to Electrostatic Discharge
(ESD) at and greater than ±15kV. In
the event of such a discharge device
may experience communication loss
between remote and modules. The
device will terminate all active outputs,
automatically place the device in a safe
state.
To recover from this, turn remote and
all modules off and turn them on after
5 sec delay using on/off switch on each.
Once the device restarts, re-initiate all
treatments.
The quality of the electrical power
supply should be that of a typical
commercial or hospital environment.
The quality of the power supply should
be that of a typical commercial or
hospital environment.
