Assembly Step 4
Loosen and remove the hexagonal head screw M12x40 (25) on the outer righthand side of the
dumbbell bar (27). Then remove:
− Spring Washer Ø12
− Washer Ø12
− Cap
− Sleeve
− Aluminium Ring
− Guide Piece
CAUTION: Only do this assembly step at the right end of the dumbbell bar (27)!
