2. Removal of Front Grille

Procedure
Step
1. Remove the service
cover.
Remove the screw and
1
remove the service
cover.
2. Remove the front grille.
Remove the 3 screws
1
of the front grille.
2 Remove the screw caps
with a flat screwdriver.
Removal Procedure
Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Procedure
Service cover
(R16452)
You can remove the front
grille without detaching the
service cover.
(R16453)
Refer to the removal
Front grille
procedure in a reverse way
when reassembling.
(R16454)
(R16266)
