Removal Of Front Grille - Daikin FTE09MV2S Service Manual

Si041138

3. Removal of Front Grille

Procedure
Step
1. Remove the service
cover.
Remove the screw of
1
the service cover.
Pull out the service
2
cover diagonally down
in the direction of the
arrow.
3 The figure shows the
inside.
2. Remove the front grille.
Open the horizontal
1
blades.
Removal Procedure
Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Procedure
Horizontal blade
Service cover
(R4851)
(R4852)
(R4853)
(R4854)
Removal of Front Grille
Points
Preparation
Remove the front panel
according to the "Removal of
Front Panel."
You can remove the front
grille without detaching the
service cover.
5
