Table Of Contents - Daikin FTKD24HV2S Service Manual

Si041144
1. Removal of Air Filters / Front Panel ........................................................2
2. Removal of Front Grille ...........................................................................5
3. Removal of Electrical Box .......................................................................7
4. Removal of PCBs..................................................................................11
5. Removal of Horizontal Blades / Swing Motors ......................................19
6. Removal of Indoor Heat Exchanger ......................................................27
7. Removal of Fan Motor / Fan Rotor........................................................31
8. Removal of Vertical blade ASSY...........................................................34
Note:
Removal Procedure

Table of Contents

The illustrations may be slightly different depending on the model.
