5. Removal of Horizontal Blades / Swing Motors

Procedure
Step
1. Remove the horizontal
blades.
Hold the indoor unit up
1
with a piece of wood
etc.
Removal Procedure
Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Procedure
Horizontal blade
left
Removal of Horizontal Blades / Swing Motors
(R16287)
(R16515)
inner right
(R16516)
