www.ti.com
7.4

Enhanced Direct Memory Access (EDMA3) Controller

The primary purpose of the EDMA3 is to service user-programmed data transfers between two memory-
mapped slave endpoints on the device. The EDMA3 services software-driven paging transfers (e.g., data
movement between external memory and internal memory), performs sorting or subframe extraction of
various data structures, services event driven peripherals such as a McBSP or the UTOPIA port , and
offloads data transfers from the device CPU.
The EDMA3 includes the following features:
Fully orthogonal transfer description
– 3 transfer dimensions: array (multiple bytes), frame (multiple arrays), and block (multiple frames)
– Single event can trigger transfer of array, frame, or entire block
– Independent indexes on source and destination
Flexible transfer definition:
– Increment or FIFO transfer addressing modes
– Linking mechanism allows for ping-pong buffering, circular buffering, and repetitive/continuous
transfers, all with no CPU intervention
– Chaining allows multiple transfers to execute with one event
256 PaRAM entries
– Used to define transfer context for channels
– Each PaRAM entry can be used as a DMA entry, QDMA entry, or link entry
64 DMA channels
– Manually triggered (CPU writes to channel controller register), external event triggered, and chain
triggered (completion of one transfer triggers another)
4 Quick DMA (QDMA) channels
– Used for software-driven transfers
– Triggered upon writing to a single PaRAM set entry
4 transfer controllers/event queues with programmable system-level priority
Interrupt generation for transfer completion and error conditions
Memory protection support
– Active memory protection for accesses to PaRAM and registers
Debug visibility
– Queue watermarking/threshold allows detection of maximum usage of event queues
– Error and status recording to facilitate debug
Each of the transfer controllers has a direct connection to the switched central resource (SCR).
Although the transfer controllers are directly connected to the SCR, they can only access
certain device resources. For example, only transfer controller 1 (TC1) can access the
McBSPs. lists the device resources that can be accessed by each of the transfer controllers.
Copyright © 2005–2012, Texas Instruments Incorporated
NOTE
C64x+ Peripheral Information and Electrical Specifications

Submit Documentation Feedback

Product Folder Link(s):
TMS320C6455
TMS320C6455
SPRS276M – MAY 2005 – REVISED MARCH 2012
105
