3-4-3-5. Information
In Information page, you can check the serial number, firmware versions, system configuration and settings of the
UPS. There are submenus under the Information, including Identification, System and Battery, as shown below.
Information displays all parameter setting value and status.
1) Identification item shows the UPS Module name, serial no, UPS display version, controller module version,
CPU version and system LCD version.
Information:
Identification
System
Bat
2) System shows the UPS configuration.
Information:
Identification
System
Bat
8. BatNum:
Set battery number in the system. The setting range is from 16 to 20 pieces.
The default value is 16.
9. Chg Curr:
Set maximum charge current. The setting range is from (0~ 4A) x N. N
represents the parallel unit number. The default value is 4A. If parallel unit
number is 10, the maximum setting value can be 40A.
10. Bat Groups: Set the number of battery group ranging from 1 to 10. The
default value is 1 group.
11. Bat Cap: Set the battery capacity such as 7AH, 9AH, 10AH, 12AH, 17AH,
26AH, 40AH, 65AH, 100AH and so on. The default value is 9AH.
12. Factor: Calibrate the displayed backup time by adjusting this multiplier
factor. The formulation is listed below:
Displayed backup time=Original calculated backup time x Multiplier factor
The value of default factor is 1.0. The setting range is from 0.5 to 2.
Item 10~12 are used for the battery backup time calculation.
Identification：
Module Name：
Arena 3-3
Serial NO:
*********
*********
Display Ver:
00.21
>>>
→
System: Bypass
Status: Open
Disable
HighLoss V: 240V
LowLoss V: 110V
HighLoss F:
54Hz
LowLoss F: 46Hz
>>>
→
32
Identification：
Control Ver：
00.00
Main Ver:
30.01
30.01
MiniLcd Ver:
02.36
<<<
→
System: ECO
Status:
Disable
HighLoss V: 240V
218V
LowLoss V:
HighLoss F: 52Hz
48Hz
LowLoss F:
>>>
→ →
