3-4-2. Main interface (Home Page)
After initialization, the main screen will display as below chart.
(1) Line Mode
IP1:230.0V/50.0Hz
IP2:230.0V/50.0Hz
IP3:230.0V/50.0Hz
OP1:230.0V/50.0Hz
OP2:230.0V/50.0Hz
OP3:230.0V/50.0Hz
Bat:192.0V/192.0V
Load:100/100/100%
Warning： 00
1) UPS Mode: Current operation mode.
2) It will display the UPS running status mode and parallel information as below table.
Short Description
3) Input and output information.
4) Battery capacity, load level and backup time/warning or fault codes. When alarms happen, the warning or
fault information will display. When UPS is operated in Battery mode or Battery Test mode, the backup time
will display.
When the front panel is not operated for 2 minutes, the display page will return back to home page. Press the
"UP" or "DOWN" button to enter the operation menu (Refer to 4.2.3).
When it displays home page in LCD, if UPS is in bypass or standby, you could press the "ON/ENTER" button to turn
on the UPS to line / CVCF / ECO / battery mode according to the setting and input status.
Bypass Mode M
IP1:230.0V/50.0Hz
IP2:230.0V/50.0Hz
IP3:230.0V/50.0Hz
OP1:230.0V/50.0Hz
OP2:230.0V/50.0Hz
OP3:230.0V /50.0Hz
Bat:192.0V/192.0V
Load: 0/ 0/ 0%
When UPS is turned on, you could press the "OFF/ESC" button to allow UPS to bypass mode or standby.
M
Main screen (Home Page)
Description
N New adding module into parallel system.
M Master
S<n> Slave, <n> means the number of slave module.
→
(2) (1) Bat Mode
IP1: 0.0V/ 0.0Hz
IP2: 0.0V/ 0.0Hz
IP3: 0.0V/ 0.0Hz
(3)
OP1:230.0V/50.0Hz
OP2:230.0V/50.0Hz
OP3:230.0V/50.0Hz
Bat:192.0V/192.0V
Load:100/100/100%
Backup Time: 10H
(4)
Turn On ?
Yes
No
→
