8.5. LED indicators

The status indicators are arranged on the EX245-DY1 as shown in the illustration below.

0 to 7

Description

OFF

Output is not activated and no errors.

Green ON

Output is activated.

Red ON

Short circuit is detected.

Fig. 8-2 Status indicators of the EX245-DY1

- 51 -

No.EX※※-OMW0011-A
