General diagnostics 2
Bit Description
0 Module 1 diagnostics
1 Module 2 diagnostics
2 Module 3 diagnostics
3 Module 4 diagnostics
4 Module 5 diagnostics
5 Module 6 diagnostics
6 Module 7 diagnostics
7 Module 8 diagnostics
・
Valve diagnostics 2
Bit Description
0 Valve 16, 17 diagnostics
1 Valve 18, 19 diagnostics
2 Valve 20, 21 diagnostics
3 Valve 22, 23 diagnostics
4 Valve 24, 25 diagnostics
5 Valve 26, 27 diagnostics
6 Valve 28, 29 diagnostics
7 Valve 30, 31 diagnostics
Table. 5-9 General diagnostics 2
0: No error or not connected, 1: Module 1 has an error
0: No error or not connected, 1: Module 2 has an error
0: No error or not connected, 1: Module 3 has an error
0: No error or not connected, 1: Module 4 has an error
0: No error or not connected, 1: Module 5 has an error
0: No error or not connected, 1: Module 6 has an error
0: No error or not connected, 1: Module 7 has an error
0: No error or not connected, 1: Module 8 has an error
Table. 5-10 Valve diagnostics 2
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
0: Short circuit, 1: No error
