SMC Networks EX245-SPN1A Operation Manual page 28

・
General diagnostics 2
Bit Description
0 Module 1 error
1 Module 2 error
2 Module 3 error
3 Module 4 error
4 Module 5 error
5 Module 6 error
6 Module 7 error
7 Module 8 error
・
Valve diagnostics 1
Bit Description
0 Valve 0, 1 diagnostics
1 Valve 2, 3 diagnostics
2 Valve 4, 5 diagnostics
3 Valve 6, 7 diagnostics
4 Valve 8, 9 diagnostics
5 Valve 10, 11 diagnostics
6 Valve 12, 13 diagnostics
7 Valve 14, 15 diagnostics
・
Valve diagnostics 2
Bit Description
0 Valve 16, 17 diagnostics
1 Valve 18, 19 diagnostics
2 Valve 20, 21 diagnostics
3 Valve 22, 23 diagnostics
4 Valve 24, 25 diagnostics
5 Valve 26, 27 diagnostics
6 Valve 28, 29 diagnostics
7 Valve 30, 31 diagnostics
Table. 5-3 General diagnostics 2
0: No error or not connected, 1: Module 1 has an error
0: No error or not connected, 1: Module 2 has an error
0: No error or not connected, 1: Module 3 has an error
0: No error or not connected, 1: Module 4 has an error
0: No error or not connected, 1: Module 5 has an error
0: No error or not connected, 1: Module 6 has an error
0: No error or not connected, 1: Module 7 has an error
0: No error or not connected, 1: Module 8 has an error
Table. 5-4 Valve diagnostics 1
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
Table. 5-5 Valve diagnostics 2
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
0: No error, 1: Short circuit
- 28 -
Explanation
Explanation
Explanation
No.EX※※-OMW0011-A
