4.1.5. Configuration steps
Enter the modules in your configuration program corresponding to the actual module layout and a
"Diagnostics type" module if required (
the actual layout, the connection to the IO Controller will not be established.
Configuration steps:
・
When using the
configuration software. When using the EX245-SPN2A/EX245-SPN3A, choose the Head
module "EX245-SPN Cu".
・
Enter the "Diagnostics type 1/2" modules in Diagnostics slot if required.
・
Enter the "16/32 Valves" module in Valves slot if use valves.
Enter the modules "EX245-DX1" and "EX245-DY1" in each module slot if modules are
・
connected (max. 8 modules).
Example of a configuration
Slot name
Diagnositics -
4 x Double solenoid
Valves
Valves
Module 1 EX245-DX1
Module 2 EX245-DX1
Module 3 EX245-DX1
Module 4 EX245-DY1
Module 5 EX245-DY1
Refer to the
choose the Head module "EX245-SPN FX" on the
EX245-SPN1A,
Diagnostics slot
Actual module Configuration module
Diagnostics type 1
16 Valves
EX245-DX1
EX245-DX1
EX245-DX1
EX245-DY1
EX245-DY1
Fig. 4-1 Example of assignment of modules
). If the configuration does not match
Section 5.1
Diagnostics type 1
Input bytes
- 23 -
Output bytes
4 -
- 2
2 -
2 -
2 -
- 1
- 1
