4.2.2. Energy saving mode for PROFIenergy
Each module has the following module parameters for PROFIenergy.
The SI Unit starts the energy saving mode when the SI Unit receives the PROFIenergy command.
Regarding the LED indicator during energy saving mode, refer to the
Parameters
Valves output
operation at pause
Parameters
Sensor supply
and input value at
pause
Parameters
Digital output
operation at
pause
Table. 4-8 PROFIenergy parameters of "16/32 Valves"
Range of values
Proceed
Force to OFF
(Default)
Hold last status
Table. 4-9 PROFIenergy parameters of "EX245-DX1"
Range of
Switch/sensor
values
supply
Proceed ON
Shut down,
Clear value
(Default)
OFF
Shut down,
Hold last
status
Table. 4-10 PROFIenergy parameters of "EX245-DY1"
Range of
values
Load supply
Proceed ON
Force to OFF
(Default)
OFF
Hold last
status
Explanation
Valves supply
ON Depending on valves behavior
Fixed 0x00
OFF
Hold last value
Explanation
Input value
Depending on
switch/sensor
behavior
Fixed 0x00
Hold last value
Explanation
Output value
Depending on
load behavior
Fixed 0x00
Hold last value
- 26 -
Section 6.4.6.
Output value
LED indicator of EX245-DX1
Depending on switch/sensor
behavior
OFF
LED indicator of EX245-DY1
Depending on load behavior
OFF
