4.1.3. Modules
The SI Unit can consists of the following modules.
Module
Diagnostics type 1
Diagnostics type 1
shared
Diagnostics type 2
Diagnostics type 2
shared
16 Valves
16 Valves shared
32 Valves
32 Valves shared
EX245-DX1
EX245-DX1 shared
EX245-DY1
EX245-DY1 shared
4.1.4. Sub modules
Using the module named as "shared", other PROFINET IO Controllers can use the copied input data
in the sub modules.
Sub module
Diagnostics type 1
shared
Diagnostics type 2
shared
16 Valves shared
32 Valves shared
EX245-DX1 shared
EX245-DY1 shared
Table. 4-2 Overview of modules for the SI Unit
Occupied bytes
Input Output
4 bytes -
4 bytes -
4 bytes -
4 bytes -
- 2 bytes
- 2 bytes
- 4 bytes
- 4 bytes
2 bytes -
2 bytes -
- 1 byte
- 1 byte
Table. 4-3 Overview of Sub modules for the SI Unit
Occupied input bytes
4 bytes
4 bytes
2 bytes
4 bytes
2 bytes
1 byte
- 22 -
Allowable slot
(Number / Name)
1 / Diagnostics Refer to the
Refer to the
1 / Diagnostics
and Table 4-3
1 / Diagnostics Refer to the
Refer to the
1 / Diagnostics
and Table 4-3
2 / Valves Refer to the
Refer to the
2 / Valves
and Table 4-3
2 / Valves Refer to the
Refer to the
2 / Valves
and Table 4-3
3..10 / module 1..8 Refer to the
Refer to the
3..10 / module 1..8
and Table 4-3
3..10 / module 1..8 Refer to the
Refer to the
3..10 / module 1..8
and Table 4-3
Bytes to be copied
4 bytes input data for diagnostics.
Refer to the Section 5.1.1.
4 bytes input data for diagnostics.
Refer to the Section 5.1.2
2 bytes output data for valve outputs.
Refer to the Section 6.3
4 bytes output data for valve outputs.
Refer to the Section 6.3
2 bytes input data for EX245-DX1 inputs.
Refer to the Section 7.4
1 byte output data for EX245-DY1 outputs.
Refer to the Section 8.4
Note
Section 5.1.1
Section 5.1.1
Section 5.1.2
Section 5.1.2
Section 6.3
Section 6.3
Section 6.3
Section 6.3
Section 7.4
Section 7.4
Section 8.4
Section 8.4
