J-Tech Digital JTECH-EXBT460 User Manual page 11

General
Bandwidth
HDMI Standard
HDCP Version
CEC
Bidirectional PoC
HDMI 2.0 Cable Length
Transmission Standard
Transmission Distance
Operation Temperature
Storage Temperature
Relative Humidity
Power Supply
Power Consumption
Dimension (W*H*D)
Net Weight
Note: Please adopt high-qualified HDMI cable fully compliant with HDMI 2.0 for
reliable transmission and connection.
(1) 3-pin terminal block
18Gbps
2.0
2.2, 1.4 compliant
Pass-through
Supported
4K@60Hz 4:4:4 ≤ 5m, 4K@60Hz 4:2:0 ≤ 15m, 1080P ≤ 20m
HDBaseT
1080P@60Hz ≤ 230 feet (70 meters),
4K@60Hz ≤ 131 feet (40 meters)
-5~ +55
℃
-25 ~ +70
℃
10%-90%
Input:100V~240V AC; Output:24V DC 1.25A
12W (Max)
TX/RX: 140mm x 19.5mm x 84mm
TX:275g, RX:290g
11
(1) 3-pin terminal block
