Technical Specification

Video
Input
Input Connector
Input Resolution
Output
Output Connector
Output Resolution
Audio
Input
Input Connector
Output
Output Connector
Audio Format
Frequency Response
Max Output Level
THD+N
SNR
Crosstalk Isolation
L-R Level Deviation
Frequency Response
Deviation
Output Load Capability
Stereo Channel
Separation
Control
Control Part
Control Connector
Transmitter
(1) HDMI
(1) Type-A female HDMI
Up to 4Kx2K@60Hz 4:4:4 8bit
HDR10
(1) HDBT Out
(1) RJ45
Up to 4Kx2K@60Hz 4:2:0
-
-
(1) ARC Audio Out
(1) Toslink connector
Supports PCM, Dolby Digital, Dolby True-HD, DTS and DTS-HD.
20Hz – 20KHz, ±3dB
2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV (316mV)
nominal consumer line level signal
< 0.05% (-80dB), 20Hz – 20KHz bandwidth, 1KHz sine at 0dBFS level
(or max level)
> 85dB, 20Hz-20 kHz bandwidth
> 70dB, 10KHz sine at 0dBFS level (or max level before clipping)
< 0.3dB, 1KHz sine at 0dBFS level (or max level before clipping)
< ± 0.5dB 20Hz - 20KHz
1KΩ and higher (Supports 10x paralleled 10KΩ loads)
>70dB@1KHz
(1) Test Pattern button,
(1)1080P → 4K button,
(1) EDID 4-pin DIP switch,
(1) FW, (1) IR In, (1) IR Out,
(1) RS232
(1) Micro-USB port,
(2) 3.5mm jacks,
10
Receiver
(1) HDBT
(1) RJ45
Up to 4Kx2K@60Hz 4:2:0
(1) HDMI
(1) Type-A female HDMI
Up to 4Kx2K@60Hz 4:4:4 8bit
HDR10
(1) ARC Audio In
(1) Toslink Connector
(1) Audio Breakout
(1) Toslink connector
(1) ARC Mode button, (1) FW,
(1) IR In, (1) IR Out, (1) RS232
(1) Micro-USB port,
(2) 3.5mm jacks,
