Chapter 2____________________________________Zaxcom Miniature Digital Recorder User's Manual
Additional microphones will be added to this list after a review of their 3.3v power performance and RF
interference susceptibility has been completed.

Non-RF Resistant Lavs

Use one of the following microphone models:
Additional microphones will be added to this list after a review of their 3.3v performance.

General

The ZFR100 has an unbalanced microphone input accessed through a 3-pin micro-LEMO connector. You can use
an unbalanced dynamic microphone or a powered lavaliere. It is recommended that you use 3-wire lavalieres with
separate pins for ground, audio and power.
When using a Line-level input, an inline pad is required on the standard dynamic microphone input cable (XLR-3 to
3-pin micro-LEMO).
When using a phantom powered microphone with the ZFR100, you must use an external 48 VDC power supply.
NOTE: Once upon a time, the Denecke 48V power supply could damage the now discontinued Goldline
transmitter‟s preamp. This is NOT the case with the ZFR100.
Brand
Audio-Technica 892*CL4
Audio-Technica 898*L4
Audio-Technica 899*L4
Isomax Instrument
Countryman
M2H*W3
Isomax Instrument
Countryman
M2C*W3
DPA Headband 4067

Table 2-2 Compatible Non-RF Resistant Lavalier Microphones

Model Voltage
3
3
3
3
1.5
3
12
Notes
Hypercardioid
Cardioid
Other headband requires 5 volts
