Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 2

Device Interface

IFB Antenna

CAUTION: The antenna is located behind the white rubber panel on the bottom of the unit. Don‟t place
anything in front of this area that could block reception. Also, don‟t allow anything to press in on this area,
the antenna and/or receiver could be damaged.

RECORD key

Pressing it puts it into RECORD mode. While in RECORD mode, pressing it for less than 1 second closes the
current file and immediately starts recording in a new file. The green LED blinks to confirm the creation of a new
file. This is done to mark a point in time to make it easier to find in post-production.

PLAY key

Pressing it replays the last recording from its beginning.

STOP key

Pressing it puts the unit into STOP mode.

INC key

Pressing it while in STOP mode, advances 2-3 seconds in the current recorded segment. If you continue pressing
it you will eventually advance to the next recorded segment.

DEC key

Pressing it while in STOP mode, moves backward 2-3 seconds in the current recorded segment. If you continue
pressing it, you will eventually move backward to the beginning of the current recorded segment. If you press it
again, you will move to the end of the previous recorded segment.
ON/OFF Switch – Internal/External Power Switch
The Power switch is intentionally set below the frame of the recorder to prevent accidentally turning it „OFF‟
during use.
When the Zaxcom Stereo Adapter is connected, the ON/OFF switch becomes an internal or external power
select switch.
No Stereo Adapter
Switch Position
„ON‟
„OFF‟

Table 2-3 Power Switch Positions

13
Stereo Adapter
Installed
„ON‟ Internal Power
„OFF‟ External Power
Installed
