Chapter 2____________________________________Zaxcom Miniature Digital Recorder User's Manual

Device Interface

Media Slot

This slot holds a MiniSD card for local recording. To insert a card, with the screen facing you, turn the card so the
finger contacts are facing away from you and down toward the slot. Insert it into the slot and press it down until
you here a slight click. To remove it, press it in until you hear the same click again.

Record Key

While in STOP mode, press it for more than 1 sec to go into RECORD mode. While in RECORD mode, press it
for less than 1 second to continue recording in a new file. Also while in RECORD mode, press it for more than 1
sec to go into STOP mode.

Unit Power Switch

Located inside the battery compartment, in the opposite end from the antenna.

ZFR800 Configuration Menus

There are seven Standard and ten Extended menu pages, as follows:
Each time the MENU key is pressed, the menu advances to the next page, in sequence.
Standard Menu
Transport Control page
Audio Gain page
Highpass Filter page
Limiter page
Timecode Frame-rate page
Media Erase & Format page
Lock page
Table 2-5 ZFR800 Standard & Extended Menus
Extended Menu
{p.18} Highpass Filter page
{p.19} Limiter page
{p.19} Power-up Mode page
{p.19} Media Erase & Format page
{p.19} Timecode Output Enable page
{p.20} Expander page
{p.21} Dynamics page
Battery Type page
Recording Mode page
Track Name page
16
{p.23}
{p.23}
{p.25}
{p.25}
{p.26}
{p.27}
{p.27}
{p.29}
{p.29}
{p.29}
