COMPONENTS DIAGRAM
Eyepieces
Binocular
Viewing Head
Light Path
Selection Slider
Adjustment Collar
UNITRON
MEC4 INVERTED METALLURGICAL MICROSCOPE
Camera/Photo
Port
Tension
Stage Plate
Extension
Stage Plate
Coarse/Fine Focus
Adjustment Knobs
Base
Metal
Carry
Insert
Handle
Mechanical
Stage
Stage
On/Off
Power Switch
X/Y Axis
Stage Control
Knobs
