- Page 1 Z650HR SERIES ZOOM STEREO MICROSCOPE MANUAL 73 Mall Drive, Commack, NY 11725 • 631-543-2000 (P) • 631-589-6975 (F) www.unitronusa.com • info@unitronusa.com...
-
Page 2: Table Of Contents
DETAILED ASSEMBLY PROCEDURE ................6 ADJUSMENT AND OPERATION ADJUSTING BINOCULAR VIEWING HEAD ..............8 FOCUS ADJUSTMENT ....................9 SPECIFICATIONS ......................10 TROUBLESHOOTING ......................11 MAINTENANCE........................12 SERVICE ..........................12 WARRANTY ........................12 ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 3: Safety Notes
A regular schedule of preventative ® maintenance by qualified service personnel is highly recommended. Your authorized UNITRON distributor can arrange for this service. ®... -
Page 4: Introduction
Z650HR STEREO MICROSCOPE INTRODUCTION ® ® Congratulations on the purchase of your new UNITRON microscope. UNITRON microscopes are engineered and manufactured to the highest quality standards. Your microscope will last a lifetime if ® used and maintained properly. UNITRON microscopes are carefully assembled, inspected and tested by our staff of trained technicians in our New York facility. -
Page 5: Assembly
When assembling the microscope, make sure that all parts are free of dust and dirt, and avoid scratching any parts or touching glass surfaces. ③ Eyepieces Trinocular Head ① ② Lock-screw Power Cord ④ Stand ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 6: Detailed Assembly Procedure
3 Avoid placing the instrument in a dusty environment. When not in use, cover the microscope with the dust cover. 4 Keep the microscope on a flat and stable surface. Fig. 3 ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... - Page 7 Fig. 5 Using the Glass Stage (Fig. 5) Set the glass stage plate ⑨ on the center of the base, and secure the slide with the two clips ⑩. ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com...
-
Page 8: Adjusment And Operation
⑥, loosen the inner screw and rotate the screw with a flat head screwdriver until the image is clear. When clear, tighten the screw and replace the screw cover. Fig. 8 ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 9: Focus Adjustment
(i.e., auxiliary 0.5 x 6=3x) Moving the Microscope Before moving the microscope, be sure to remove any slide/samples. When moving the microscope, hold the stand and base to keep it level. ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 10: Specifications
18-150X 13.3-1.6 0.5X 3-25X 76.7-9.2 4.5-37.5X 53.3-6.4 6-50X 40-4.8 9-75X 26.7-3.2 0.7X 4.2-35X 54.8-6.6 6.3-52.5X 38.1-4.6 8.4-70X 28.6-3.4 12.6-105X 19.0-2.3 12-100X 19.2-2.3 18-150X 13.3-1.6 24-200X 10-1.2 36-300X 6.7-0.8 ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 11: Troubleshooting
Loosen it to a suitable position The image is obscure because of the The focusing knob is to o loosen Tighten it to a suitable position head slipping down during observation ® UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com... -
Page 12: Maintenance
UNITRON® distributor or UNITRON® at (631) 543-2000. This warranty is limited to the continental United States of America. All items returned for warranty repair must be sent freight prepaid and insured to Unitron Ltd., 73 Mall Drive, Commack, NY 11725 – USA. All warranty repairs will be returned freight prepaid to any destination within the continental United States of America.
