Operation and Maintenance Manual
FOR TONGUE AND GROOVE FLOORING 3/8" TO 5/8"
Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you
are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or
contact the closest Powernail Dealer for help. Please retain this information for future reference.
POWERNAIL
1300 Rose Road, Lake Zurich, IL 60047
Phone: 1-800-323-1653
Website: www.powernail.com
MODEL 50M FLEX
MANUAL POWERNAILER
50M FLEX with Adjustable Foot
®
WARNING
CO.
®
REV 06.19.19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Powernail POWERNAILER 50M FLEX
Summary of Contents for Powernail POWERNAILER 50M FLEX
- Page 1 Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference. REV 06.19.19...
-
Page 2: Tool Operation
Never place any part of the body in the discharge path of the Nailer. DESCRIPTION The Model 50M FLEX Powernailer® is the latest model designed to bring Powernail quality to a manual nailer. The Powernailer® Model 50M—designed for use with only 1"... - Page 3 FLEX Foot Adjustment: FLEX Adjustment Lever Wood varies from one manufacturer to the next. The diff erent wood profi les may be due Figure 1. to height and length of the fl ooring tongue and whether or not there is a nail pocket. First, loosen the two hex bolts under the FLEX foot with the Allen Wrench supplied with the nailer.
- Page 4 Model 50M FLEX Parts List ITEM # PART NO. DESCRIPTION Qty Req 08-50M00630 BODY ASSEMBLY 08-50M00150 FOOT 08-50M00380 DRIVING BLADE 07-50M00370 PLUNGER 08-25000450 PLUNGER SPRING 08-25000410 PLUNGER SPRING PIN 08-25000640 ROLLER PIN 08-25000750 1/4-20 FLANGE NUT 09-2003034 PUSHER SPRING 09-2003035 SPOOL SET 09-50P3005 ADAPTER FOOT...
- Page 5 50M FLEX Schematic For this and other Powernailer schematics, please visit the Powernail Parts Store at http://www.powernail.com Model 50M FLEX Assemblies, Kits & Accessories ITEM # PART NO. DESCRIPTION Qty Req AW-200 ALLEN WRENCH SET 09-50M3065A CHANNEL ASSEMBLY 09-2003063A NAIL PUSHER ASSEMBLY...
- Page 6 WARNING Never hit the Nailer with excessive force or with the metal end of the mallet, this will damage the nailer. Before each use, check all screws to be sure they are tight. Shock and vibration can loosen screws. Do not over tighten any screw. TO CLEAR A NAIL JAM: 1.
- Page 8 Visit www.Powernail.com • Dealer Locator • Repair Tech Videos • Rental Locator • Cool Tools Cleat Calculator • Parts Store • Cleat Depth Chart • Product Information • Training Schools Featured Products Powerjack® Model 500 Truly a Tinker's TOOL, the POWERJACK Model 500 is designed to push or pull fl...
