Operation and Maintenance Manual
FOR TONGUE AND GROOVE FLOORING 3/8" TO 5/8"
Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you
are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or
contact the closest Powernail Dealer for help. Please retain this information for future reference.
POWERNAIL
1300 Rose Road, Lake Zurich, IL 60047
Phone: 1-800-323-1653
Website: www.powernail.com
MODEL 50M FLEX
MANUAL POWERNAILER
50M FLEX with Adjustable Foot
®
WARNING
CO.
®
08.11.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50M FLEX MANUAL POWERNAILER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powernail 50M FLEX MANUAL POWERNAILER

Summary of Contents for Powernail 50M FLEX MANUAL POWERNAILER

  • Page 1 Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference. 08.11.09...

  • Page 2: Tool Operation

    Never place any part of the body in the discharge path of the Nailer. DESCRIPTION The Model 50M FLEX Powernailer® is the latest model designed to bring Powernail quality to a manual nailer. The Powernailer® Model 50M—designed for use with only 1"...
  • Page 3 FLEX Foot Adjustment: FLEX Adjustment Lever Wood varies from one manufacturer to the next. The diff erent wood profi les may be due Figure 1. to height and length of the fl ooring tongue and whether or not there is a nail pocket. First, loosen the two hex bolts under the FLEX foot with the Allen Wrench supplied with the nailer.
  • Page 4 Model 50M FLEX Parts List ITEM # PART NO. DESCRIPTION Qty Req 08-50M-00-630 BODY ASSEMBLY 08-50M-00-150 FOOT 08-50M-00-380 DRIVING BLADE 07-50M-00-370 PLUNGER 08-250-00-450 PLUNGER SPRING 08-250-00-410 PLUNGER SPRING PIN 08-250-00-640 ROLLER PIN 08-250-00-740 1/4-20 X 1-3/4 S.H.C.S. (FOOT) 08-250-00-750 1/4-20 FLANGE NUT 09-200-3034 PUSHER SPRING 09-200-3057...
  • Page 5 50M FLEX Schematic For this and other Powernailer schematics, please visit the Powernail Parts Store at http://www.powernail.com Model 50M FLEX Assemblies, Kits & Accessories ITEM # PART NO. DESCRIPTION Qty Req AW-200 ALLEN WRENCH SET 09-50M-3065A CHANNEL ASSEMBLY 09-200-3063A NAIL PUSHER ASSEMBLY...
  • Page 6 WARNING Never hit the Nailer with excessive force or with the metal end of the mallet, this will damage the nailer. Before each use, check all screws to be sure they are tight. Shock and vibration can loosen screws. Do not over tighten any screw. TO CLEAR A NAIL JAM: 1.
  • Page 7 POWERCLEATS LENGTH DETERMINATION CHART 1-3/4” 18 GAGE POWERCLEATS® 13/16” 1-1/2” 18 GAGE POWERCLEATS® 5/8” 1-1/4” 18 GAGE POWERCLEATS® 1” 18 GAGE POWERCLEATS® 15/32”...
  • Page 8 By working the lever the crooked plank is drawn into the existing fl ooring. A Powernail Nailer then nails the board into place. To release the Powerjack® simply push the handle fully forward.
