Specifications
525-600 V
Enclosure Power [kW]
A2 0-75-4.0
A3 5.5-7.5
A5 0.75-7.5
B1 11-18
B2 22-30
B3 11-15
B4 18.5-30
C1 37-55
C2 75
C3 37-45
C4 55-75
Table 8.15 525-600 V, Enclosure Types A, B and C
525-690 V
Enclosure Power [kW]
A3 1.1
1.5
2.2
3
4
5.5
7.5
B2/B4 11
15
18
22
B4/C2 30
C2/C3 37
45
C2 55
75
Table 8.16 525-690 V, Enclosure Types A, B and C
MG33AP02
Operating Instructions
Recommended Recommended
fuse size maximum fuse
gG-10
gG-10 (5.5)
gG-16 (7.5)
gG-10 (0.75-5.5)
gG-16 (7.5)
gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-63 (37) gG-160 (37-45)
gG-100 (45) aR-250 (55)
aR-160 (55)
aR-200 (75)
gG-63 (37)
gG-100 (45)
aR-160 (55)
aR-200 (75)
Recommended Recommended
fuse size maximum fuse
gG-6
gG-6
gG-6
gG-10
gG-10
gG-16
gG-16
gG-25 (11)
gG-32 (15)
gG-32 (18)
gG-40 (22)
gG-63 (30) gG-80 (30)
gG-63 (37) gG-100 (37)
gG-80 (45) gG-125 (45)
gG-100 (55) gG-160 (55-75)
gG-125 (75)
