1.1.2 Available Literature

NOTE
This design guide contains the basic information necessary
for installing and running the frequency converter.
Danfoss technical literature is available in print from local
Danfoss Sales Offices or online at: Danfoss website /
BusinessAreas/DrivesSolutions/Documentations
- VLT Micro Drive FC 51 Quick Guide, MG02B
VLT Micro Drive FC 51 Programming Guide, MG02C
-
- FC 51 LCP Mounting Instruction, MI02A
- FC 51 De-coupling Plate Mounting Instruction,
MI02B
- FC 51 Remote Mounting Kit Mounting Instruction,
MI02C
- FC 51 DIN Rail Kit Mounting Instruction, MI02D
- FC 51 IP21 Kit Mounting Instruction, MI02E
- FC 51 Nema1 Kit Mounting Instruction, MI02F
- FC 51 Line Filter MCC 107 Installation Instruction,
MI02U

1.1.3 Symbols

The following symbols are used in this manual.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
CAUTION
Indicates a situation that may result in equipment or
property-damage-only accidents.
NOTE
Indicates highlighted information that should be regarded
with attention to avoid mistakes or operate equipment at
less than optimal performance.
