VLT
Micro Drive Selection
Step 3
Place bracket on back of the LCP, then slide down. Tighten
screws and connect cable to LCP.
NOTE
Use the provided thread cutting screws to fasten
connector to LCP. Tightening torque: 1.3 Nm.
Illustration 4.7
Illustration 4.8
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
®
VLT
Micro Drive FC 51 Design Guide
Step 4
Connect cable to frequency converter.
NOTE
Use the provided thread cutting screws to fasten
connector to the frequency converter. Tightening torque:
1.3 Nm.
Illustration 4.9
®
MG02K202 - VLT
is a registered Danfoss trademark
4
4
