- Page 1 Motor Handpiece System for Root Canal Enlargement OPERATION MANUAL OM-E0202E 001 Please Read this operation manual carefully before use and keep for future reference.
-
Page 2: Table Of Contents
Thank you for purchasing the EndoDrive PLUS. This product should be used by qualified personnel for dental purposes only. This product is used primarily for root canal enlargement. Read this Operation Manual carefully before use for operation instructions, care and maintenance. Keep this Operation Manual for future reference. - Page 3 • Check the product before use, paying attention to looseness, vibration, noise and temperature (heat generation). If any abnormal condition is found even slightly at that time, immediately stop use and contact Brasseler USA. • Do not allow any impact on to the Product. Do not drop the Product.
-
Page 4: Features
• EndoDrive PLUS should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, EndoDrive PLUS should be observed to verify normal operation in the configuration in which it will be used. -
Page 5: Specifications
2. SPECIFICATIONS < Control Unit > < Motor Handpiece > Model Model NE131 EM13M Rated input Rated input DC20V 0.5A DC7V 0.4A Output Dimensions DC7V 0.4A Ø20 × L108mm Charging time 5hours approx. Weight ( including motor handpiece cord ) Dimensions W92 x D148 x H124mm Weight... - Page 6 Operation Panel and LCD Panel. ( Operation Panel ) ( Operation Panel ) (LCD Panel) REVERSE Key REVERSE Key AC IN Lamp AC IN Lamp SPEED Key SPEED Key CHARGE Lamp CHARGE Lamp AUTO REVERSE Key AUTO REVERSE Key TORQUE Key TORQUE Key This indicates that all displays are lighted.
- Page 7 • PROGRAM Key • A program can be selected. The present program number is displayed. The program number is available from 1 to 9. • The alarm sound volume can be adjusted. (Refer to P.14 6. (5) “Alarm Sound Volume Control”) The present alarm mark is displayed.
- Page 8 • AUTO REVERSE Key The auto reverse mode can be selected by this key. (Refer to P.11 “ Auto Reverse Function.”) The present auto reverse mode mark is displayed. AUTO REVERSE If the load is removed after auto reverse rotation, it returns to the normal rotation again. AUTO STOP If the load is removed after autoreverse rotation, it stops.
-
Page 9: How To Connect Each Part
Foot Control Connector with the mark of the plug Foot Control Connector Foot Control Connector down. (Fig. 5) * The Foot Control is optional and is not required to operate the EndoDrive PLUS. Foot Control (option) Plug Foot Control (option) Plug Fig. 5... -
Page 10: How To Use
5. HOW TO USE REVERSE Key AC IN Lamp SPEED Key CHARGE Lamp TORQUE Key AUTO REVERSE Key PROGRAM Key POWER Key Fig. 6 MEMORIZE Key GEAR RATIO Key (1) Charge (if batteries are used) 1) Insert the AC adapter plug into a power supply. 2) Confirm the AC IN lamp light is green. - Page 11 (2) Changing Contra Angle Head Positioning Pin Positioning Slots • The contra angle head can be connected with the motor handpiece at 6 adjustable head positions. Align the positioning pins of the contra angle head with the positioning slots of the motor handpiece and insert the head until they click.
- Page 12 (5) Operation ON/OFF Button 1) • Start the motor handpiece to pressing the ON/OFF button briefly. Press the button again to stop the handpiece. (Alternate operation) • Keep pressing ON/OFF button more than a second, the motor handpiece starts while the button is pressed. If you release the button, it stops.
-
Page 13: Convenient Functions
AUTO REVERSE OFF The motor handpiece stops without reverse rotation. In this instance, the LCD panel shows “ ” and the rotation speed alternately. NOTICE • When the reverse rotation (R) is set, the Auto Reverse Function is not activated. •... - Page 14 NOTICE • This function is not activated unless this product is powered by the AC adapter. • If this function is used, all programs will disappear and return to the originally set values. Record the present program details according as needed. (3) Battery Refresh Nickel-metal-hydride batteries may result in a decrease in charging capacity, if additional charging (repeating a cycle of short-time use and recharging) is made.
-
Page 15: Cleaning
(5) Alarm Sound Volume Control The alarm sound volume can be controlled at the three steps of “BIG VOLUME, SMALL VOLUME and LIMITED OFF. ” 1) Keep pressing both buttons of the PROGRAM key simultaneously. 2) The alarm mark on the LCD panel changes, and the sound volume changes. 3) Release the PROGRAM key when the sound volume reaches your required level and the required sound level is set up. -
Page 16: Changing Batteries
When replacing them yourself, be sure to observe the following “ CAUTIONS ON CHANGING BATTERIES.” Note that Brasseler USA shall not be held liable for any malfunction or failure resulting from your not following the “ CAUTIONS ON CHANGING BATTERIES.”... -
Page 17: Error Code
NOTICE The used nickel metal hydride batteries are recyclable, but their disposal may sometimes not be permitted by local laws. Return them to Brasseler USA. 10. ERROR CODE If the motor handpiece stops due to an abnormality such as a malfunction, overload, break or wrong use, it automatically checks the state of the control unit and detects the cause of the abnormality and displays an error code on the LCD panel. -
Page 18: Troubleshooting
11. TROUBLESHOOTING When trouble is found, check the following again before contacting Brasseler USA. If none of these is applicable or the trouble is not remedied even after action has been taken, a failure of this product is suspected. Contact Brasseler USA. - Page 19 Remove the foot control (Option), and rotate There is a short circuit inside the Foot the motor handpiece by the ON/OFF button, Control. (Option) or contact Brasseler USA. The motor handpiece keeps rotating. (The Foot Control It is rotated by the ON/OFF button.
-
Page 20: Warranty
This mark is machine tool, electrical equipment and medical equipment Safety mark in Canada. Guidance and manufacturer's declaration - electromagnetic emissions The EndoDrive PLUS is intended for use in the electromagnetic environment specified below. The customer or the user of the EndoDrive PLUS should assure that is used in such an environment. - Page 21 Guidance and manufacturer's declaration - electromagnetic immunity The EndoDrive PLUS is intended for use in the electromagnetic environment specified below. The customer or the user of the EndoDrive PLUS should assure that it is used in such an environment. Immunity test...
- Page 22 Recommended separation distances between portable and mobile RF communications equipment and the EndoDrive Plus. The EndoDrive PLUS is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EndoDrive PLUS can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EndoDrive PLUS as recommended below, according to the maximum output power of the communications equipment.
- Page 23 *Specifications may be changed without notice. By Your Side in Dentistry One Brasseler Boulevard, Savannah, GA 31419 To order call 800.841.4522 or fax 888.610.1937. Visit our website: www.BrasselerUSA.com...
