Summary of Contents for BRASSELER USA Forza F5
- Page 1 Contra Angle Attachments Please read this Operation Manual carefully before use and file for future reference.
- Page 2 • Always keep bur shanks clean. Dirt or debris in a chuck could cause poor bur concentricity or low chuck retention force. • Do not use the bur other than those recommended by Brasseler USA and do not exceed the speed recommended by the bur manufacturers.
- Page 3 Contact with cheek tissue may cause the push-button to depress and an injury to the patient may occur. • Even with irrigation, if the bearing is worn, the handpiece may overheat or vibrate loudly. If this occurs, contact Brasseler USA for a...
- Page 4 1. Mounting/Removing the Handpiece and Motor 1) Mounting Align the handpiece to the motor and push together. For F5 and F1 (optic). Locate the handpiece and alignment pin straight into positioning of the motor. 2) Removing Hold the motor and the handpiece and pull off carefully in a straight line.
- Page 5 2. Lubrication Supply spray after each use and/or before autoclaving. E-type Spray Nozzle Handpiece 1) Mount the E-type spray nozzle over the spray nozzle until it firmly seats. 2) Shake the can 3-4 times to well mix lubricant and propellant. 3) Insert the E-type spray nozzle in the rear of the handpiece and spray for approximately 2-3 seconds until the oil comes out of the handpiece head.
-
Page 6: Cleaning And Sterilization
3. Cleaning and Sterilization This product can be washed via Thermo Disinfector. Brasseler recommends heat sterilization by autoclave. • Sterilization is required before using for the first time and after each patient as noted below. Autoclave Procedure : 1) Scrub dirt and debris from the handpiece, and wipe clean with alcohol-immersed cotton swab or cloth. Do not use a wire brush. - Page 7 Caution • In case the sterilizer chamber temperature could exceed 135ºC during the dry cycle, skip the dry cycle. • Always place the handpiece in the center or upper shelf of the chamber, as the local temperature at the chamber bottom could rise beyond the set value.
- Page 8 Remove all debris and oil. (Fig.2) Glass Rod End Fig. 2 Caution Do not use a sharp tool to clean the Cellular Glass Optic Rod. It could damage the glass and reduce the light transmission. If illumination becomes dim, contact Brasseler USA.
- Page 10 5a. Specifications Model Forza F5 Gear Ratio 1:5 Increasing Max. Rotation Speed (Motor) 40,000 RPM Max. Rotation Speed (Bur) 200,000 RPM Four Port Spray Spray Glass Rod Optic Glass Rod Bur Type ISO 1797-1, Type 3 (Ø1.59 - 1.60mm Standard Bur)
- Page 11 5b. Mounting/Removing Bur Mounting the Bur 1) Depressing the push button 2) Insert the bur into the chuck. (Fig.3) 3) Make sure it inserted firmly till the end of the head. (Fig.3) Fig. 3 Removing the Bur 1) Press the button 2) Pull the bur from the head.
- Page 13 6a. Specifications Forza F5X Model 1:5 Increasing Gear Ratio 40,000 RPM Max. Rotation Speed (Motor) 200,000 RPM Max. Rotation Speed (Bur) Four Port Spray Spray Non-Optic Glass Rod Optic ISO 1797-1, Type 3 (Ø1.59 - 1.60mm Standard Bur) Bur Type Coolant Delivery External...
- Page 14 6b. Mounting/Removing Bur Mounting the Bur 1) Insert the bur into the chuck. (Fig.5) 3) Make sure it inserted firmly till the end of the head. (Fig.5) Fig. 5 Removing the Bur 1) Press the button 2) Pull the bur from the head. (Fig.6) Fig.
- Page 15 6c. Irrigation Nozzle When irrigation is required, please connect the irrigation tube to the irrigation nozzle. Irrigation Tube Irrigation Nozzle F 5 X Handpiece Motor Fig. 7...
- Page 18 7b. Mounting/Removing Burs Connecting 1) Mount handpiece and Micromotor. 2) Insert the bur into the head and turn the bur slightly. (If bur and head are properly positioned, the bur will be seated all the way in the head) 3) Insert the bur into the head until it clicks. (Fig.8) Removing 1) Press the button and pull the bur from the head.
-
Page 19: Warranty
Brasseler USA warrants the handpiece against defects in manufacturing, workmanship and materials. Brasseler USA reserves the right to analyze and determine the cause of any problem. Warranty is voided should the handpiece not be used in accordance with this manual. - Page 20 By Your Side in Dentistry One Brasseler Boulevard, Savannah, GA 31419 To order call 800.841.4522 or fax 888.610.1937. Visit our website: www.BrasselerUSA.com...
