High Speed Air Turbine Handpiece Please read this Operation Manual carefully before use and le for future reference. Handpiece should not be used with friction grip burs exceeding 18.5 mm in length.
Page 2
• Refer to the coupling manual before connecting it to the handpiece tubing. • Do not attempt to disassemble the handpiece or tamper with the mechanism. * Brasseler USA® does not recommended the repair and disassembly. This may cause the handpiece to perform abnormally and could result in damage, failure or accidents.
1. Speci cation Model Brasseler Mini Miniature Head Type 380,000 ~ 450,000 min -1 Rotation Speed Single Spray Spray Type Push Button Chuck Chuck Type ISO1797-1 Type3 Ø1.59~1.60mm Short Shank Bur/Shorter-than-Short Shank Bur Minimum Bur Fixing Length: 8.0 mm Maximum Bur Length: 18.5 mm Bur Length Ø...
Page 4
2. Caution on burs CAUTION • Do not use non-standard burs. The ISO standard shank diameter is Ø1.5.9-Ø1.60mm • Fully depress the Push Button and insert the bur into the chuck until bur is secure. • Do not use bur when removing the crown, do not use bur to pry loose the crown. It may cause a malfunction in the handpiece. •...
Page 5
3. Mounting and Removing the Bur Mounting the bur 1 ) Insert the bur until it stops. ( 2 ) Depress the Push Button. ( 3 ) Insert the bur into the chuck until it is stops again. ( 4 ) Release the button. Fig.
Page 6
4. Connecting/Disconnecting the Handpiece Coupling Hose 1) Align the pipes of the coupling and the pipe holes of the hose, and push the coupling onto the hose. Hold the coupling tightly and fasten the nut of the hose securely. (Fig. 2) 2) Insert the handpiece rmly onto the coupling until it clicks to engage.
Page 7
5. Lubrication Supply spray after each use (after cleaning the holes) and/or before autoclaving. 1) Push spray nozzle attachment over the SPRAY can nozzle until it firmly seats. 2) Insert the spray nozzle in the rear of the handpiece and spray for approximately 2-3 seconds. Handpiece Spray Nozzle Fig.
Page 8
6. Chuck Cleaning Nozzle Tip Perform the cleaning of the chuck once a week for Push Button Chuck (FG bur). Chuck Cleaning Method 1) Mount the arrow-head spray nozzle tip into the spray port. 2) Lubricate chuck directly through the hole where the bur is inserted. Fig.
Page 9
7. Clean Head System Maintenance Clean Head Hole 1 ) Brush off the debris at the clean head holes. (Fig. 6) Do not use a wire brush . 2 ) Half ll a cup with clean water. 3 ) Rotate the handpiece and immerse half of the handpiece head. ( Fig. 7 ) 4 ) Rotate and stop intermittently the handpiece about 2 to 3 seconds.
Page 10
8. Spray Port Maintenance When the spray ports are clogged, or spray does not exit evenly from the ports, clean the Cleaning Wire ports as follows: 1 ) Remove the bur from the chuck. Spray Ports 2 ) Take out the cleaning wire from the back end of the brush holder. Insert the wire straight into the spray ports with caution.
Page 11
Remove all debris and oil. Glass Rod Fig. 9 CAUTION Do not use a sharp tool to clean the cellular glass optic rod. It could damage the glass and reduce the light transmission. If illumination becomes dim please contact Brasseler USA®.
Page 12
10. Sterilization Autoclave sterilization is recommended. Autoclave sterilization required first time you use and after each patient (after lubrication) as noted below. Autoclave Procedure 1) Scrub dirt and debris from the handpiece, and wipe clean with alcohol-immersed cotton swab or cloth. Do not use a wire brush. 2) Lubricate with spray.
If the O-Ring remains, the new Turbine can not be inserted properly. • Use only Brasseler USA® genuine turbines. If you use other Turbine, specification may not be satisfied and void the warranty. • The head cap screw thread is very fine. To prevent damage to the thread always first tighten the handpiece head cap using fingers, then secure with the head cap wrench.
12. Replacing the O-Rings Loosen Taper Ring Replace the O-Rings if water is present in the exhaust air line. This is an indication of possible water leakage within the coupling. ALWAYS change the complete set of O-Rings. 1 ) Loosen and Remove the Taper Ring at the rear of the handpiece. ( Fig. 11 ) 2 ) Gently remove each O-Ring with your thumb.
Page 15
Coupling Joint, which shuts off the water retraction right at the handpiece head, to prevent Gasket oral uids from being sucked into the water line. Brasseler USA® Coupling Remove the back-end Gasket. Pull and remove the water tube, and replace the Non-Retraction Non-Retraction Valve Water Tube Valve.
Page 16
By Your Side in Dentistry One Brasseler Boulevard, Savannah, GA 31419 To order call 800.841.4522 or fax 888.610.1937. Visit our website: www.BrasselerUSA.com...
