HygienePro
Thank you for purchasing the Hygiene Pro Cordless.
This product is a cordless handpiece used mainly for polishing teeth (professional mechanical tooth
cleaning [PMTC]). Read this Operation Manual carefully before use for operation instructions, care
and maintenance. Keep this Operation Manual for future reference.
Cautions for handling and operation
Read these safety cautions thoroughly before use and operate the product properly.
These indicators are to allow you to use the product safely and prevent danger and harm to you
and others. These are classified by degree of danger, damage and seriousness. All indicators
concern safety, be sure to follow them.
Classification
DANGER
WARNING
CAUTION
NOTICE
• This product is designed specifically for use with rechargeable batteries. Do not use manganese
or alkaline batteries. Using and charging these by error may cause a fluid leak or explosion.
• Always replace both batteries with the same type at the same time. Using batteries
of different-types or an exhausted battery with a fully charged one may cause a fluid leak
or explosion.
Cordless Handpiece
Degree of Danger or Damage and Seriousness
Explains an instruction where death or serious injury may occur.
Explains an instruction where bodily injury or damage to device may occur.
Explains an instruction where possibility for minor to medium bodily injury
or damage to device may exist.
Explains an instruction that should be observed for safety reasons.
DANGER
™
OM-ER225E 001
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BRASSELER USA HygienePro
Summary of Contents for BRASSELER USA HygienePro
- Page 1 HygienePro ™ Cordless Handpiece OM-ER225E 001 Thank you for purchasing the Hygiene Pro Cordless. This product is a cordless handpiece used mainly for polishing teeth (professional mechanical tooth cleaning [PMTC]). Read this Operation Manual carefully before use for operation instructions, care and maintenance.
- Page 2 • If you should notice a battery fluid leak within the motor handpiece, deformation of the motor-handpiece casing or partial discoloring, immediately stop use and contact Brasseler USA. • If the product will not be used for a long period of time, remove the batteries to avoid fluid leak.
-
Page 3: Specifications
NOTICE • The motor handpiece is designed with the commercially available AAA nickel metal hydride batteries (rechargeable). Ni-Cad batteries can also be used, but the charging time and operating time become significantly shorter since the charging current differs. • The motor handpiece consumes electricity very slightly even when the power is off. In addition, fully-charged rechargeable batteries, in general, discharge gradually over time even though it is not used. -
Page 4: Packaging Contents
3. Packaging Contents Battery charger Power cord Motor handpiece Motor cap F-type spray nozzle Contra head DPA-4 (For Disposable Prophy Angles 4:1 Reduction) Fig. 1... - Page 5 Operation Panel Details This section describes the names and functions of each switch and lamp on the motor handpiece operation panel. For more detailed operations of the motor handpiece, refer to the "Operating Motor Handpiece" in 4. (2). ON/OFF switch Power/Rotation Speed Selector switch Battery lamp Rotation Speed lamp...
-
Page 6: Operation Procedures
Power lamp If the power lamp or charge lamp flashes, turn on the power switch once again. If they still flash, contact Brasseler USA. 4 ) Remove the contra head from the motor handpiece and mount the motor cap onto it. -
Page 7: Emergency Stop Function
Notice · Battery could be fully charged even if charge lamp does not light, depending on the remaining amount of the battery charge. · When the handpiece is inserted onto the charger after it is not used for long with the battery inserted, the handpiece sometimes could not be charged. - Page 8 (3) Changing Contra Head Positioning pin Positioning slots The contra head can be connected with the motor handpiece at 6 adjustable head positions. Align the positioning pins of the contra head with the positioning slots of the motor handpiece and insert the head until they click.
-
Page 9: Safety System
In such a case, wait until the motor handpiece cools. If this safety system occurs repeatedly, either the batteries or motor handpiece is not in the normal operating condition, contact Brasseler USA... -
Page 10: Changing Batteries
NOTICE" may be applicable, or the life of the batteries could be exhausted. In such a case, ask Brasseler USA to replace the batteries or replace them with new ones by yourself. (Refer to the "S Changing Batteries.") When replacing them by yourself, be sure to observe the following "... - Page 11 Changing Batteries Rubber cover Battery cover Small screwdrivers are required (Phillips, flathead). 1 ) Turn off the power of the motor handpiece. 2 ) Remove the rubber cover from the battery cover with a thin flathead screwdriver. Fig. 11 (Fig. 11) 3 ) Remove the screw fixing the battery cover with a Phillips screwdriver.
-
Page 12: Operation Panel Display
If the lamps flash after Abnormal temperature at the battery the handpiece has been chamber. (Battery short circuit, over left for a while, Contact discharge, etc.) Brasseler USA. Abnormal Motor Voltage A The circuit is damaged. Contact Abnormal motor voltage. -
Page 13: Troubleshooting
11. Troubleshooting When trouble is found, please check the following again before contacting Brasseler USA. If none of these is applicable or the trouble is not remedied even after action has been taken, a failure of this product is suspected. Contact your Brasseler USA. - Page 14 By Your Side in Dentistry One Brasseler Boulevard, Savannah, GA 31419 To order call 800.841.4522 or fax 888.610.1937. Visit our website: www.BrasselerUSA.com ‘08.08.005 M...
