Qam 16 Blade; Qam16 Blade; Qam 48 Blade; Qam48 Blade - Dish Network Smartbox User Manual

QAM 16 Blade

Dimensions (H x W x D)
Power Consumption
Connector
Output Frequency
Channel Bandwidth
Modulation
QAM Symbol Rate
Interleaving
Channel Plans
Output Frequency
Accuracy
Output Level
Output Attenuation
Output Level Flatness
Spurious
Output Impedance
Output Return Loss

QAM 48 Blade

Dimensions (H x W x D)
Power Consumption
Connector
Output Frequency
Channel Bandwidth
Modulation
QAM Symbol Rate
Interleaving
Channel Plans
Output Frequency
Accuracy
Output Level
Output Attenuation
Output Level Flatness
Spurious
Output Impedance
Output Return Loss
7.5 x 0.9 x 13.5
25W (typical)
F-Female
54–1002 MHz
16 channels, 6 MHz per channel
ITU-T J.83B Annex B (256QAM), Inverse
5.360537 MSps
128/1 Annex B
EIA, HRC, IRC, Manual
125 Hz
45 dBmV effective precombined output power
0 to 10 dB (0.5 dB step)
(54 to 864 MHz) ±1 dB
(864 to 1002 MHz) ±2 dB
> 60 dBc (in 4MHz)
75 ohms
>11 dB
7.5 x 0.9 x 13.5
50W (typical)
F-Female
54 to 1002 MHz
48 channels, 6 MHz per channel
ITU-T J.83B Annex B (256QAM), Inverse
5.360537 MSps
128/1 Annex B
EIA, HRC, IRC, Manual
125 Hz
45 dBmV effective precombined output power
0 to 10 dB (0.5 dB step)
(54 to 864 MHz) ±1 dB
(864 to 1002 MHz) ±2 dB
> 60 dBc (in 4MHz)
75 ohms
>11 dB
