CHAPTER 15 MANUAL FACTORY DEFAULT

If at any point you lose the ability or documentation to access the
to take the SMARTBOX manually through a factory reset. Only follow these steps if ABSOLUTELY necessary.

Factory Default Without Access to User Interface

Performing this will remove all user settings from the system and return to factory defaults.
1. Remove power from the system
2. Remove all blades from the system
3. Place one blade into slot 16
4. Power system up
5. Wait to see all 4 satellite input LEDs flashing green
6. While the satellite input LEDs are flashing green, remove the blade from slot 16
7. The satellite input LEDs will begin to flash red
8. The regular booting process will now start
9. You may reinsert blades into system for use
56
SMARTBOX user interface, there are steps
