Figure 26 EVOLVE - Refresh now button when adding a service
5. Click the Details arrow of the file to configure the service, then click the Add another Output button
6. Select the Type
NOTE: On QAM systems, the files can only be assigned to the same QAM carrier as the DVB-SI. On IP systems,
separate multicast addresses will need to be configured for each service. The multicast address must be different
for each service, while the ports can be the same or different for every service depending on the network
configuration. This applies to both the provisioning files and content streams.
7. Enter in the Output (for IP only)
8. Configure the bitrate for the service and click Apply
NOTE: The bitrate determines how quickly the data from the file is sent out to the EVOLVE units. The combined
bitrates of all the EVOLVE provisioning services cannot exceed 20,000 Kbps regardless of output type. It is
recommended that larger files such as EVOLVE software or App APKs be assigned higher bitrates. The bitrates
can be reconfigured as needed depending on the current files being output.
EVOLVE-Bitrate Example 1
File Type
Provisioning File
EPG Logos
App APK
EVOLVE Software
EVOLVE-Bitrate Example 2
File Type
Provisioning File
EPG Logos
App APK 1
App APK 2
EVOLVE Software
48
Bitrate
1000 Kbps
1000Kbps
6000Kbps
12000 Kbps
Bitrate
1000 Kbps
1000 Kbps
4000 Kbps
4000 Kbps
10000 Kbps
