Time (Clock) - Labkotec idOil-30 3G Installation And Operating Instructions Manual

Installation and Operating Instructions | idOil-30 3G, idOil-30 Battery 3G
Do the following to set unique names for sensors.
Send the following text message command to the idOil unit's phone number:
The unit's response includes the names of the device and the sensor inputs. Please note
the fixed portion of the sensor input names.
Example 2:
Enter the following command to rename sensor input 2.
Device response:
4.2.3.

Time (CLOCK)

The time setting is needed if you wish to save log information with actual time stamps or if
you want the device to send timed messages to the end user or the LabkoNet server.
This setting can also be entered via the idOil unit's browser user interface.
The format of the time setting command is:
Field legend
CLOCK
<yyyy-mm-dd>
<hh:mm>
Example
Do the following to set the time.
Send the following message to the idOil device:
The device responds as follows:
In addition to the time, the response includes a possible name set for the device in
question.
DI 1: Separator 1. 2: Separator 1. 3: Separator 1.
DI <device name>
1: Separator 1 / Oil level sensor
2: Separator 1 / High liquid sensor
3: Separator 1 / Sludge level sensor
DI 2: Separator 1 Pirkkala
DI <device name>
1: Separator 1 / Oil level sensor
2: Separator 1 Pirkkala / High liquid sensor
3: Separator 1 / Sludge level sensor
CLOCK <yyyy-mm-dd> <hh:mm>
CLOCK 2018-10-23 15:30
CLOCK <device name> 2018-10-23 15:30
Time setting command and query
Year (yyyy), month (mm) and date (dd)
separated with a hyphen.
Hours (hh) and minutes (mm) separated
with a colon.
9/19
DOC001696-EN-1
