Installation and Operating Instructions | idOil-30 3G, idOil-30 Battery 3G
4.4.2.

Listening interval (LI)

A listening interval can be set for the device, according to which it will wake up from power
saving mode, activate the 3G modem and read any possible setting messages and queries
that have been sent to it. The device performs any possible setting commands and
responds to any possible queries. After this, the device returns to power saving mode.
The factory default for the listening interval is 12 hours. The listening takes plays every 12
hours from device activation.
This setting can also be entered via the idOil unit's browser user interface.
The format of the listening interval setting is as follows:
Field legend
LI
<nn>
Example:
If Pirkkala Myllyhaantie has been set as the device name and the command
is sent, the response is:
4.4.3.

Operating voltage alarm limit setting (VLIM)

The idOil-30 Battery 3G unit monitors the level of its operating voltage. The device sends an
alarm when the voltage drops below the alarm limit setting specified for the operating
voltage.
The factory default for the alarm limit is 11.4 V.
This setting can also be entered via the idOil unit's browser user interface.
The setting command for the operating voltage alarm limit is formatted as follows:
Field legend
VLIM
<xx.x>
A 0.2 V hysteresis has been set for alarm removal. In other words, the alarm removal limit
is 0.2 V higher than the setpoint. The hysteresis value cannot be changed.
Example:
If the device name has been set as Pirkkala Myllyhaantie and the command is:
LI <nn>
LI 24
LI Pirkkala Myllyhaantie 24
VLIM <xx.x>
Command
Listening interval in hours. Permitted values
12, 24, 36, 48.
Setting command for the operating voltage
alarm limit
The desired voltage in volts with one
decimal. The integer and decimal are
separated with a point. Permitted values: 0
(setting off), 10.5–99.9
