Installation and Operating Instructions | idOil-30 3G, idOil-30 Battery 3G
5.

Information requested from the unit

5.1.

Alarm information query (M)

To request alarm information from the device,
send the following message to the idOil device:
The device responds as described below by sending the device name, sensor names and
alarm or fault information. The information of each sensor input is on a separate row of the
message.
The field legends are listed in the following tables.
Field legend
STATUS
<device name>
<sensor input name> /
<alarm text>
<yyyy-mm-dd> <hh:mm>
<fault alarm text>
<yyyy-mm-dd> <hh:mm>
Example 1:
M
STATUS <device name>
<sensor input 1 name> / <sensor input 1 alarm or fault status> <yyyy-mm-dd>
<hh:mm>
<sensor input 2 name> / <sensor input 2 alarm or fault status> <yyyy-mm-dd>
<hh:mm>
<sensor input 3 name> / <sensor input 3 alarm or fault status> <yyyy-mm-dd>
<hh:mm>
STATUS Pirkkala Myllyhaantie
Oil level alarm 2018-05-31 13:05
Heading of command M
If a name has been set for the device, it is
indicated at the beginning of the message.
The possible descriptive name set by the
user for the sensor input and the character
"/".
Alarm text (standard, cannot be changed,
depends on the type of sensor connected to
the input):
Oil level alarm on ( or off),
Sludge level alarm on ( or off),
High liquid alarm on ( or off).
Alarm time.
Alarm text regarding the fault (standard,
cannot be changed, depends on the type of
sensor connected to the input):
Oil level fault on ( or off)
Sludge level fault on ( or off)
High liquid fault on ( or off).
Alarm time.
14/19
DOC001696-EN-1
