- Page 1 USER MANUAL PG Series & Ultrasound Series PG SERIES ULTRASOUND SERIES made in the USA with US & imported parts www.oakworksmed.com · 717.235.6807...
- Page 2 ® damages in connection with or arising out of the furnishing, performance, or OAKWORKS is a registered use of this document and the program ® trademark of OAKWORKS , Inc. material which it describes. ®...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Product Use Description ..........................1 Important Safety Instructions Symbol Identification ......................... 1 Safety Instructions .......................... 1-2 Product Description & Photo PG350 ..............................3 PG300 ..............................4 PG200 ..............................5 General - General with Fowler - General 3 Section ..............6 Women’s Imaging .......................... -
Page 4: Product Use Description
PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS PRODUCT USE DESCRIPTION The PG and Ultrasound Tables are used to support the patient during examinations and procedures. It is intended to be operated by a healthcare professional in a medical environment. No special training is required but a review of the following Safety Instructions is important for the safety of the operator and patient. - Page 5 3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use. 4. Keep the cord away from heated surfaces.
-
Page 6: Product Description & Photo
PRODUCT DESCRIPTION PG350 Paper roll holder Manual 4 Electric position leg Backrest rest foot control Electric Lift Towers Locking Casters optional hand control STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38” (55.9-96.5 cm.) Height Range Central Base Locking System Motion 2 Powered ±15º... -
Page 7: Pg300
PRODUCT DESCRIPTION PG300 Paper roll holder Electric Backrest foot control Electric Lift Towers Locking Casters optional hand control STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38” (55.9-96.5 cm.) Height Range Central Base Locking System Motion 2 Powered ±15º Trendelenburg/ Reverse Side Rails (2) Trendelenburg Hand Control - All powered motions Motion 3... -
Page 8: Pg200
PRODUCT DESCRIPTION PG200 Paper roll foot control holder Electric Lift Towers Locking Casters optional hand control STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38” (55.9-96.5 cm.) Height Range Central Base Locking System Motion 2 Powered ±15º Trendelenburg/ Reverse Side Rails (2) Trendelenburg Hand Control - All powered motions Foot Control... -
Page 9: General - General With Fowler - General 3 Section
PRODUCT DESCRIPTION General Paper roll Shown with Optional Fowler (Back Rest) holder (1) Upholstered Top Optional electric Fowler (1) hand control Electric Lift Towers (2) optional foot control Locking Casters (4) STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38” (55.9-96.5 cm.) Height Range Electric Fowler Motion 2 Powered ±15º... -
Page 10: Women's Imaging
PRODUCT DESCRIPTION Paper roll Women’s Imaging holder (1) Electric Fowler Adjustable angle back support (Right side is standard) hand control Electronic Lift Towers (2) Adjustable Stirrups (2) Manual Adjustable Four Position optional foot control Leg Section Locking Casters (4) STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38”... -
Page 11: Multi-Specialty
PRODUCT DESCRIPTION Electric fowler Multi-Specialty Paper roll holder (1) Adjustable angle back support (2) Electronic Lift Towers (2) hand control Adjustable Stirrups (2) Manual Central Base Adjustable Locking System Four Position Leg Section Locking Casters (4) foot control STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38”... -
Page 12: Echocardiography
PRODUCT DESCRIPTION Electric Fowler Paper roll Echocardiography holder (1) Sliding Cardio Panel Electronic Lift Adjustable Towers (2) angle back hand control support (Right side is standard) Locking Casters (4) foot control - manual cardio foot control - electric cardio STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-38”... -
Page 13: Vascular With Fowler
PRODUCT DESCRIPTION Vascular with Fowler Paper roll holder (1) Electric Fowler Patient Side Rail (2) Restraint Strap (1) hand control Electronic Lift Towers (2) optional foot control Integrated Locking Foot Board (2) Casters (4) STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 23”-40” (58.4-101.6 cm.) Height Range Central Base Locking System Motion 2 Powered 15º... -
Page 14: Vascular
PRODUCT DESCRIPTION Vascular Paper roll holder (1) Patient Restraint Strap (1) hand control Side Rail (2) Electronic Lift Towers (2) optional foot control Integrated Locking Foot Board (2) Casters (4) STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 23”-40” (58.4-101.6 cm.) Height Range Central Base Locking System Motion 2 Powered 15º... -
Page 15: Installation
INSTALLATION All tables come completely assembled and ready to use. Plug the cord into a functioning outlet that is rated for the table. (see Grounding below) Arrange the power cord and control cords so that they will not create a tripping hazard and where the controls are located to your liking and are conveniently accessible. -
Page 16: Directions For Use
DIRECTIONS FOR USE CONTROL OPERATIONS - PG200 Do not sit on the Fowler (Backrest) or Leg Rest sections. CAUTION Do not leave the patient unattended. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) The Foot Control and optional Hand Control operate all functions of the table with the touch of a button. -
Page 17: Pg300
DIRECTIONS FOR USE CONTROL OPERATIONS - PG350 & PG300 Do not sit on the Fowler (Backrest) or Leg Rest sections. CAUTION Do not leave the patient unattended. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) Height Up: optional hand control... -
Page 18: General
DIRECTIONS FOR USE CONTROL OPERATIONS - GENERAL Do not sit on the Fowler (Backrest) or Leg Rest sections. CAUTION Do not leave the patient unattended. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) The Hand Control and optional Foot Control operate all functions of the table with the touch of a button. -
Page 19: General With Fowler, Multi-Specialty & Women's Imaging
DIRECTIONS FOR USE CONTROL OPERATIONS - MULTI-SPECIALTY, WOMEN’S IMAGING & GENERAL WITH FOWLER Do not sit on the Fowler (Backrest) or Leg Rest sections. CAUTION Do not leave the patient unattended. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) Reverse Trendelenburg: Trendelenburg:... -
Page 20: Electric Sliding Cardio Panel Tables
DIRECTIONS FOR USE CONTROL OPERATIONS - MULTI-SPECIALTY & ECHOCARDIOGRAPHY WITH ELECTRIC SLIDING PANEL Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unattended. Do CAUTION not sit on the cardio panel. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) Reverse Trendelenburg: Trendelenburg:... -
Page 21: Vascular With Fowler
DIRECTIONS FOR USE CONTROL OPERATIONS - VASCULAR WITH FOWLER Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unattend- CAUTION ed. The Patient Restraint Strap must be used during all procedures. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) Reverse Trendelenburg:... -
Page 22: Vascular
DIRECTIONS FOR USE CONTROL OPERATIONS - VASCULAR Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unattend- CAUTION ed. The Patient Restraint Strap must be used during all procedures. When lowering the table or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) Reverse Trendelenburg:... -
Page 23: Side Rail Use
Then lift slightly and push into the storage position. DETACHABLE ARM BOARD USE CAUTION Do not put excessive weight or pressure on the Arm Board. This product can be used on any of Oakworks ultrasound tables with a T-Rail Adapter and can support a variety of positioning configurations. -
Page 24: Adjustable Angle Back Support
DIRECTIONS FOR USE ADJUSTABLE ANGLE BACK SUPPORT CAUTION Do not sit on the Adjustable Angle Back Support. (Max Capacity 150 lbs. (68 kg.)) TO RAISE BACK SUPPORT TO LOWER BACK SUPPORT Lift panel to desired angle. Panel will Press support bar against plastic plate and hold automatically lock into nearest set point. -
Page 25: Manual Adjustable 4 Position Leg Rest Use
DIRECTIONS FOR USE MANUAL ADJUSTABLE FOUR POSITION LEG REST USE CAUTION Do not sit on the Fowler (Backrest) or Leg Rest. (Max Capacity 150 lbs. (68 kg.)) TO LOWER THE LEG REST TO RAISE THE LEG REST Raise the leg rest above horizontal to unlock the Raise the leg rest by pulling it up from the lower center latch. -
Page 26: Sliding Cardio Panel
DIRECTIONS FOR USE SLIDING CARDIO PANEL USE Make sure all parts of the patient’s anatomy are clear of the sliding cardio panel when closing. CAUTION Do not sit or put excessive weight on the sliding cardio panel. (Max Capacity 150 lbs. (68 kg.)) The Sliding Cardio Panel allows you to adjust the opening of the size you need, up to 15”... -
Page 27: Vascular Patient Restraint Strap
DIRECTIONS FOR USE TO MOVE THE FOOT BOARD TO THE 4” (10 cm.) POSITION Grasp the rod at 90º With your second Grasp the rod at 90º With your second Grasp the rod at 90º bend and push into hand, grasp the foot bend and pull to the hand, grasp the foot bend and pull away... -
Page 28: Quicklock Face Rest
DIRECTIONS FOR USE TABLE EXTENDER USE CAUTION Do not put excessive weight or pressure on the table extender. The Table Extender lengthens the table allowing for access to the patient’s neck for exams such as carotid artery and thyroid. Locate the Accessory NOTE: You will need an Mounting Plate. -
Page 29: Patient Lift Compatible Base
DIRECTIONS FOR USE PATIENT LIFT COMPATIBLE BASE This option allows the use of patient lifts. The high clearance base permits patient lifts to slide easily under the center of the table for stable transfers. This option must be ordered with table. •... -
Page 30: Cleaning & Disinfection
To reduce the risk of electric shock: DANGER - Always unplug this furnishing from the electrical outlet before cleaning. The following cleaners were tested by OAKWORKS ® and found to be acceptably compatible with all materials used in construction of our tables: Formula 409 ®... -
Page 31: Cleaning Process
- Always unplug this furnishing form the electrical outlet before cleaning. ® Follow the cleaners/disinfectant manufacturers’ directions for use. Please note that cleaning and disinfecting an OAKWORKS table is a two part process. First it must be cleaned of any visible soil, then it can be disinfected. The table should be cleaned as soon as possible after use. -
Page 32: Model Number & Serial Number
U S G N X X X X X X X X 3 M T T X X X X Options Spaces not used Fabric: TerraTouch Padding: Comfort Plus Table Top Length Minimum Table Height Table Width Base GN: Ultrasound Series EX: PG Series Table US: Ultrasound Series PG: PG Series... -
Page 33: Specifications
SPECIFICATIONS PRODUCT SPECIFICATIONS Weight 359-452 lbs. (163-205 kg.) Shipping Weight 452-544 lbs. (205-247 kg.) Lifting Capacity 550 lbs. (250 kg.) ENVIRONMENTAL CONDITIONS Conditions Temperature Humidity Atmospheric Pressure Normal Use 50° (10°C) to 104° (40°C) 20% to 60% RH 98 to 105 kPa Storage &... -
Page 34: Guidance And Manufacturer's Declaration - Electromagnetic Emissions
SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic emissions The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Emissions Test Compliance Electromagnetic environment - guidance The table uses RF energy only for its internal... -
Page 35: Guidance And Manufacturer's Declaration - Electromagnetic Immunity
SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance... -
Page 36: Electromagnetic Immunity
SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance... - Page 37 THIS PAGE IS INTENTIONALLY LEFT BLANK...
- Page 38 THIS PAGE IS INTENTIONALLY LEFT BLANK...
- Page 39 THIS PAGE IS INTENTIONALLY LEFT BLANK...
-
Page 40: Contact Information
USER MANUAL PG Series & Ultrasound Series CONTACT INFORMATION: Inc. ® AKWORKS 923 East Wellspring Road New Freedom, PA 17349 Phone: 717-235-6807 FAX: 717-235-6798 www.oakworksmed.com 3034177 CONFORMS TO: ANSI/AAMI STD ES60601-1 IEC STD 60601-1 3RD EDITION IEC STD 60601-1-2 3RD EDITION IEC STD 60601-1-6 3RD EDITION CERTIFIED TO CAN/CSA STD C22.2 NO.
