Summary of Contents for OAKWORKS ProLuxe Series
- Page 1 Series Electric Salon Top Shown with optional Adjustable Breast Comfort (ABC) System Flat Top Lift-Assist Salon Top Shown with optional Adjustable Breast Comfort (ABC) System Lift-Assist Backrest Top made in the USA with US & imported parts www.OAKWORKS.com · 717.235.6807...
- Page 2 OAKWORKS , Inc. tial damages in connection with or ® arising out of the furnishing, per- formance, or use of this document OAKWORKS is a registered and the program material which it ® trademark of OAKWORKS , Inc. describes. ®...
-
Page 3: Table Of Contents
Recommended Cleaners/Disinfectants .............. 22 Cleaning Process ....................22 Inspections & Maintenance ..................23 Warranty Information ....................23 Model Number & Serial Number Proluxe Series ....................24 Specifications Product Specifications ..................25 Environmental Conditions .................. 25 Electrical Specifications ..................25 Guidance and manufacturer’s declaration - Electromagnetic emissions ................ -
Page 4: Product Use Description
There are no known contraindications to the use of this equipment. The ProLuxe Series should not be used in any other manner than that described within this manual. Use of any unnecessary force or unauthorized procedures could result in injury to practitioner, client or equipment. - Page 5 2. Unplug from outlet before adding or removing parts. 3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use at 717.235.6807.
-
Page 6: Product Description & Photo
PRODUCT DESCRIPTION Proluxe 1-Section Flat Top STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 19”-36.5” (48-93 cm.) Height Range Adjustable Breast Comfort (ABC) System Foot Control Height Range Dual Locking Casters Table Voltage Options 120V/60Hz - 230V/50Hz Cabi/ Storage Shelves Table Capacity 550 lbs. -
Page 7: Proluxe™ Lift Assist Backrest Top
PRODUCT DESCRIPTION Proluxe 2-Section Lift-Assist Backrest Top STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 21.5”-39” (54-100 cm.) Height Range Adjustable Breast Comfort (ABC) System Motion 2 Manual 0-80º Backrest Dual Locking Casters Foot Control Height Range Cabi/ Storage Shelves Table Voltage Options 120V/60Hz - 230V/50Hz Integrated Heated Top ACCESSORIES... -
Page 8: Proluxe™ Lift Assist Salon Top
PRODUCT DESCRIPTION Proluxe 4-Section Lift-Assist Salon Top STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 21.5”-39” (54-100 cm.) Height Range Adjustable Breast Comfort (ABC) System Motion 2 Manual 0-80º Backrest Dual Locking Casters Motion 3 Manual 0-30º Foot Rest Cabi/ Storage Shelves Foot Control Height Range Integrated Heated Top... -
Page 9: Proluxe™ Electric Salon Top
PRODUCT DESCRIPTION Proluxe 4-Section Electric Salon Top STANDARD SPECIFICATIONS OPTIONS Motion 1 Powered 22”-40” (57-102 cm.) Height Range Adjustable Breast Comfort (ABC) System Motion 2 Powered 0-70º Backrest Dual Locking Casters Motion 3 Powered 0-30º Foot Rest Cabi/ Storage Shelves Foot Control All powered motions Integrated Heated Top... -
Page 10: Installation
INSTALLATION The Tables come completely assembled and ready to use. Plug the cord into a functioning outlet that is rated for the table. (See Grounding below) Arrange the power cord and control cords so that they will not create a tripping hazard and where the controls are located to your liking and are conveniently accessible. -
Page 11: Foot Control Operations - Flat Top And Lift-Assist Tables Only
B A C K R E S T A N D S A L O N T A B L E S O N L Y CAUTION Be sure the self-locking molded rubber feet are flat side down to ensure safety and stability. The Oakworks Proluxe Flat Top, Lift-Assist Backrest, and Lift-Assist Salon tables offer height position- ®... -
Page 12: Foot Control Operations - Electric Salon Tables Only
The hood area under the backrest top is not designed for stor- age. DO NOT use this area for holding anything. Damage can occur to the table. The Oakworks Proluxe Electric Salon tables offer height, backrest and footrest positioning with elec- ®... -
Page 13: Foot Control Operations - Adjustable Breast Comfort System
CAUTION use as intended. For safety of your client, use a cloth sheet between the ABC System and your client. The Oakworks Adjustable Breast Comfort (ABC) System is designed to lower the pressure on breasts ® and pectoral muscles, allowing the client to relax and create a more comfortable position for their spine. -
Page 14: Directions For Use
H A N D C O N T R O L O P E R A T I O N S - F L A T T O P & L I F T A S S I S T T A B L E S The Oakworks... -
Page 15: Hand Control Operations - Electric Salon Tables Only
The hood area under the backrest top is not designed for storage. Do not use this area for holding anything. Damage can occur to the table. The Oakworks Proluxe Electric Salon tables offer height, backrest and footrest positioning with elec- ®... -
Page 16: Hand Control Operations - Adjustable Breast Comfort (Abc) System
ABC System Weight Limit - 100 lbs. (45 kg.) Do not place foreign objects into the ABC System. Only use as intended. For safety of your client, use a cloth sheet between the ABC System and your client. The Oakworks Adjustable Breast Comfort (ABC) System is designed to lower the pressure on breasts ®... -
Page 17: Adjusting The Back Rest Section
DIRECTIONS FOR USE LIFT-ASSIST BACKREST ADJUSTMENT CAUTION Do not sit on the backrest section. TO RAISE THE BACKREST TO LOWER THE BACKREST: Raise the back rest by pressing the lever Press the lever under the head section and under the head section and lifting up to push the back rest down. -
Page 18: Moving The Table
DIRECTIONS FOR USE M O V I N G T H E T A B L E CAUTION Before moving any of the tables, disconnect the power cord from the power outlet. The table weighs as much as 200 lbs. (91 kg.) Use extreme caution when lifting the table to move it. -
Page 19: Hot Towel Cabi & Storage Shelf
DIRECTIONS FOR USE H O T T O W E L C A B I S H E L F & S T O R A G E S H E L F • The Anti-Tip Strap must be installed when using a Hot Towel Cabi. CAUTION •... -
Page 20: Adjustable Breast Comfort (Abc) System (Option)
• For safety of your client, use a cloth sheet between the ABC System and your client. The Oakworks Adjustable Breast Comfort (ABC) System is designed to lower the pressure on breasts and pectoral ® muscles, allowing the client to relax and create a more comfortable position for their spine. The height of the cushion is easily adjusted up and down in small increments by using the hand control. -
Page 21: Integrated Heated Top (Option)
DIRECTIONS FOR USE INTEGRATED HEATED TOP (OPTION) USING THE INTEGRATED HEATED TOP: The table comes with the option for a fully integrated heated top pad. Simply press the heating indicator located on the right side rail of the table to the desired heat level. The heat can reach up to 40 C (105 °... -
Page 22: Quicklock Face Rest (Accessory Option)
DIRECTIONS FOR USE QuickLock FACE REST: (ACCESSORY OPTION) • QuickLock Face Rest Weight Limit - 25 lbs (11.3 kg) CAUTION • Do not put excessive weight or pressure on the Face Rest. • Excessive pressure can cause premature failure of the Face Rest. Double articulating action provides nearly limitless positioning options with the QuickLock Face Rest. -
Page 23: Adjustable Side Arm Rests (Accessory Option)
DIRECTIONS FOR USE ADJUSTABLE SIDE ARM RESTS (ACCESSORY OPTION - SALON ONLY) • Do not use the arm rest for client support during the mounting or dismounting CAUTION of the chair. • The arm rest is not designed to support the client’s weight. TO INSTALL THE ARM RESTS: The Arm Rests adjust automatically as the back rest moves to remain parallel to the floor. -
Page 24: Boiance Shelf Support (Accessory Option)
DIRECTIONS FOR USE BOIANCE SHELF SUPPORT: (ACCESSORY OPTION) • Boiance Shelf Support Weight Limit - 25 lbs (11.3 kg) CAUTION • Do not put excessive weight or pressure on the Boiance Shelf Support. • Excessive pressure can cause premature failure of Boiance Shelf Support. USING THE BOIANCE SHELF SUPPORT: The shelf and bracket used together allow you to create the perfect place for clients’... -
Page 25: Cleaning & Disinfection
Follow the cleaners/disinfectant manufacturers’ directions for use. Please note that cleaning and disinfect- ing an OAKWORKS ® table is a two part process. First it must be cleaned of any visible soil, then it can be disinfected. The table should be cleaned as soon as possible after use. Please follow these procedures for best results: 1. -
Page 26: Inspections & Maintenance
• Clean unusual buildup of dirt on the table and/or parts of the table not normally cleaned on a regular basis. • Check for tears or cracks in the upholstery. W A R R A N T Y View complete warranty details at www.oakworks.com... -
Page 27: Model Number & Serial Number
MODEL NUMBER & SERIAL NUMBER M O D E L & S E R I A L N U M B E R The model number and serial number are located on the underside of the foot section. Serial Number Model Number 16796025 PXXA4EX1T410USXXXXXX Ser#:PXR563146 Proluxe Electric Salon w/ABC 1/T/4/10/US/XX/XX/XX... -
Page 28: Specifications
SPECIFICATIONS PRODUCT SPECIFICATIONS Table Weights: 151-202 lbs. (68-92 kg.) Lifting Capacity 550 lbs. (250 kg.) ENVIRONMENTAL CONDITIONS Conditions Temperature Humidity Atmospheric Pressure Normal Use 50° (10°C) to 104° (40°C) 20% to 60% RH 98 to 105 kPa Storage & Transport -20°... -
Page 29: Guidance And Manufacturer's Declaration - Electromagnetic Emissions
SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic emissions The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Emissions Test Compliance Electromagnetic environment - guidance The table uses RF energy only for its internal... -
Page 30: Guidance And Manufacturer's Declaration - Electromagnetic Immunity
SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance... - Page 31 SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance...
-
Page 32: Contact Information
USER MANUAL Series ProLuxe ™ C O N T A C T I N F O R M A T I O N: Oakworks Inc. ® 923 East Wellspring Road New Freedom, PA 17349 Phone: 717.235.6807 FAX: 717.235.6798 www.oakworks.com 3034177...
