CHAP. 5 - Data programming
ALL View of the last alarm triggered
Minimum compressor pressure alarm
The absolute pressure referring to the
Intake probe below which, once the Ald
delay time is activated, the LOW pressure
alarm is triggered showing ELc alternating
A1C with the pressure on the display and the
flashing of the alarm icon.
When the alarm turns off, the "alarm
presence" icon will remain lit to indicate
which operation has occurred until the
alarm button is pressed.
Maximum compressor pressure alarm
The absolute pressure referring to the
Intake probe above which, once the Ald
delay time is activated, the HIGH pressure
alarm is triggered showing EHc alternating
A2C
with the pressure on the display and the
flashing of the alarm icon.
When the alarm turns off, the "alarm
presence" icon will remain lit to indicate
which operation has occurred until the
alarm button is pressed.
Minimum fan pressure alarm
The absolute pressure referring to the
delivery probe below which, once the Ald
delay time is activated, the LOW pressure
alarm is triggered showing ELu alternating
A1U with the pressure on the display and the
flashing of the alarm icon.
When the alarm turns off, the "alarm
presence" icon will remain lit to indicate
which operation has occurred until the
alarm button is pressed.
Maximum fan pressure alarm
The absolute pressure referring to the
delivery probe above which, once the Ald
delay time is activated, the HIGH pressure
alarm is triggered showing EHu alternating
A2U with the pressure on the display and the
flashing of the alarm icon.
When the alarm turns off, the "alarm
presence" icon will remain lit to indicate
which operation has occurred until the
alarm button is pressed.
Day start time programming (ignored if
tdS
dnE=0 or there is a night digital input)
Day end time programming (ignored if
tdE
dnE=0 or there is a night digital input)
Rev. 02-18
(A1C+0,2) ÷ +30,0
(A1U+0,2) ÷ +30,0
USE AND MAINTENANCE MANUAL
VISION SC600
Alarm code
-0,6 ÷ (A2C-0,2)
Bar, step 0,2 Bar
Bar, step 0,2 Bar
-0,6 ÷ (A2U-0,2)
Bar, step 0,2 Bar
Bar, step 0,2 Bar
00:00 ÷ 23:59
00:00 ÷ 23:59
Read only
-0,6 bar
+30,0 bar
-0,6 bar
+30,0 bar
06:00
22:00
