VISION SC600
8.
9.
LOW
PRESS.
TEMP.
°C
HIGH
PRESS.
HIGH
PRESS
5.5
For the operator's safety and practicality, VISION SC600 system envisions three
programming levels; the first for configuration of the frequently amendable SET POINT
parameters only, the second for programming and setting the main parameters relating to
the various board functioning modes, and the third for programming input/output of the
board. It is not possible to directly access the second or third level from the first level
programming, exit current programming first.
USE AND MAINTENANCE MANUAL
Pag. 14

Stand-by

(flashing in stand-by. Outputs are disabled)
Outputs status display
(compressors – compressors capacity – fans).
(flashing if waiting t1c/u, t2 c/u, t3 c/u, t4 c/u time)
Each output is displayed with a couple of squares to indicate whether the
output X is in "Compressor ON", "Fan ON" or "Compressor partition-ON".
During configuration, the compressors are always associated to the first exit,
then there are partitions and finally the fans (left to right).
Compressor partition X ON
Fan X ON
Compressor X ON
Intake sensor reading (low pressure) in Bar.
Intake sensor reading (low pressure) in °C.
On = delivery sensor reading (high pressure) in Bar.
Off = delivery sensor reading (high pressure) in °C.

GENERALITY

CHAP. 5 - Data programming
Rev. 02-18
