Type Code and Selection Gui... VLT Decentral Drive FCD 302
Not all choices/options are available for each FCD 302
variant. To verify if the appropriate version is available,
consult the Drive Configurator on the Internet:
http://driveconfig.danfoss.com.
NOTE
A and D options for FCD 302 are integrated into the
control card. Therefore pluggable options for frequency
converters cannot be used here. Future retrofit will require
exchange of the entire control card. B options are
pluggable, using the same concept as for frequency
5 5
converters.

5.1.1 Drive Configurator

Design the frequency converter according to the
application requirements by using the ordering number
system.
Order standard drives and drives with integral options by
sending a type code string describing the product to the
local Danfoss sales office, for example:
FCD302P2K2T4B66H1X1XMXCXXXXXA0BXXXXXXDX
The meaning of the characters in the string can be located
in the pages containing the ordering numbers in this
chapter. In the example above, a Profibus DP V1 and a 24
V back-up option is included in the drive.
From the Internet based Drive Configurator, configure the
right drive for the right application and generate the type
code string. The Drive Configurator will automatically
generate an eight-digit sales number to be delivered to
the local sales office.
Furthermore, establish a project list with several products
and send it to a Danfoss sales representative.
The Drive Configurator can be found on the global
Internet site: www.danfoss.com/drives.
The frequency converter will automatically be delivered
with a language package relevant to the region from
which it is ordered.
To order a different language package, contact the local
Danfoss sales office.
®
