Resolver Option Mcb 103 - Danfoss VLT Decentral Drive FCD 302 Design Manual

Type Code and Selection Gui...
5 5
Illustration 5.2 Connections for 5 V Incremental Encoder
Max. cable length 10 m.
1 2
Illustration 5.3 Connections for Hiperface Encoder - 1
78
Z
A
/Z
/A
B
+5V
/B
GND
3 4 5 6 7 8 9
Hiperface encoder
®
MG04H102 - VLT
®
VLT Decentral Drive FCD 302
Illustration 5.4 Connections for Hiperface Encoder - 2
Item
1
Table 5.6 Legend

5.3.3 Resolver Option MCB 103

The MCB 103 Resolver Option is used for interfacing
resolver motor feedback to the frequency converter.
Resolvers are used basically as motor feedback device for
permanent magnet brushless synchronous motors.
The resolver option kit comprises:
•
•
10 11 12
Selection of parameters: 17-5x resolver Interface.
MCB 103 Resolver Option supports a various number of
resolver types.
Resolver Poles
Resolver Input
Voltage
Resolver Input
Frequency
Transformation ratio 17-53 Transformation Ratio: 0.1–1.1 *0.5
Secondary input
voltage
Secondary load
Table 5.7 Resolver Option MCB 103 Specifications
®
is a registered Danfoss trademark
+RS485
+cos
-RS485
7-12V
-cos
+sin
-sin
GND
Description
Hiperface encoder
MCB 103 Resolver Option
Cable to connect customer terminals to control
card
17-50 Poles: 2 *2
17-51 Input Voltage: 2.0–8.0 Vrms *7.0Vrms
17-52 Input Frequency: 2–15 kHz
*10.0 kHz
Max 4 Vrms
App. 10 kΩ
1
