3.2 Input: Mains-side Dynamics

3.2.1 Connections

3.2.1.1 Cables General

NOTE
Cables General
All cabling must comply with national and local
regulations on cable cross-sections and ambient
temperature. Copper (75 °C) conductors are recommended.

3.2.1.2 Connection to Mains and Earthing

For installation instructions and location of terminals refer
to FCD 302 Operating Instructions, MG04F.
®
VLT Decentral Drive FCD 302
Mains connection
Illustration 3.4 Large Unit only: Circuit Breaker and Mains
Disconnect
1 Looping terminals
2 Circuit breaker
Table 3.1 Legend
Illustration 3.5 Large Unit only: Service Switch at Mains with
Looping Terminals
1 Looping terminals
Table 3.2 Legend
®
