Emission Requirements; Immunity Requirements - Danfoss VLT Decentral Drive FCD 302 Design Manual

Product Overview
RFI filter type
Standards and EN 55011
requirements
EN/IEC 61800-3
H1
FCD302 0.37-3 kW
Table 2.2 EMC Test Results (Emission, Immunity)

2.2.3 Emission Requirements

According to the EMC product standard for adjustable
speed frequency converters EN/IEC 61800-3:2004 the EMC
requirements depend on the intended use of the
Category Definition
C1 Frequency converters installed in the first environment (home and office) with a
supply voltage less than 1000 V.
C2 Frequency converters installed in the first environment (home and office) with a
supply voltage less than 1000 V, which are neither plug-in nor movable and are
intended to be installed and commissioned by a professional.
C3 Frequency converters installed in the second environment (industrial) with a supply
voltage lower than 1000 V.
C4 Frequency converters installed in the second environment with a supply voltage
equal to or above 1000 V or rated current equal to or above 400 A or intended for
use in complex systems.
Table 2.3 Emission Requirements
When the generic emission standards are used the
frequency converters are required to comply with the
limits in Table 2.4
Environment Generic standard
First environment EN/IEC 61000-6-3 Emission standard for residential, commercial
(home and office) and light industrial environments.
Second environment EN/IEC 61000-6-4 Emission standard for industrial environments.
(industrial environment)
Table 2.4 Emission Limit Classes

2.2.4 Immunity Requirements

The immunity requirements for frequency converters
depend on the environment where they are installed. The
requirements for the industrial environment are higher
than the requirements for the home and office
®
VLT Decentral Drive FCD 302
Conducted emission
Class B Class A Group 1
Housing, trades Industrial
and light environment
industries
Category C1 Category C2
First First environment
environment Home and office
Home and
office
No 10 m
frequency converter. Four categories are defined in the
EMC product standard. The definitions of the 4 categories
together with the requirements for mains supply voltage
conducted emissions are given in Table 2.3.
environment. All Danfoss frequency converters comply
with the requirements for the industrial environment and
consequently comply also with the lower requirements for
home and office environment with a large safety margin.
®
MG04H102 - VLT is a registered Danfoss trademark
Radiated emission
Class A Group 2 Class B
Industrial Housing, trades
environment and light
industries
Category C3 Category C1
Second environment First environment
Industrial Home and office
10 m No
Conducted emission requirement
according to the limits given in EN
Class A Group 1
Class A Group 2
No limit line.
An EMC plan should be made.
Conducted emission requirement
according to the limits given in EN 55011
Class A Group 1
Class A Group 1
2
Industrial
environment
Category C2
First
environment
Home and office
Yes
55011
Class B
Class B
15
