5.2 Ordering Numbers

5.2.1 Ordering Numbers: Accessories

Accessories
Mounting brackets extended
Mounting brackets
LCP cable
Brake resistor 1750 Ω 10 W/100%
Brake resistor 350 Ω 10 W/100%
VLT Control Panel LCP 102
5 5
Venting membrane, goretex
PE termination, M20
PE termination, M16
Table 5.2 Ordering Numbers: Accessories

5.2.2 Ordering Numbers: Spare Parts

Spare parts
Protection cover
Gasket
Accessory bag
Service switch
LCP plug
Main termination board
M12 sensor plugs
Control card
Control card Profibus
Control card EtherNet
Control card Profinet
Table 5.3 Ordering Numbers: Spare Parts
The packaging contains:
•
Accessories bag, supplied only with order of
installation box. Contents:
-
-
-
-
-
•
Documentation
Depending on options fitted, the box will contain one or
two bags and one or more booklets.
76
®
VLT
Description
40 mm brackets
Flat brackets
Preconfectioned cable to be used between inverter and LCP
For mounting inside installation box below motor terminals
For mounting inside installation box below motor terminals
Graphical display for programming and read out
Preventing condensation inside enclosure
Stainless Steel
Stainless Steel
Description
Plastic protection cover for inverter part
Gasket between installation box and inverter part
Spare cable clamps and screws for shield termination
Spare switch for mains or motor disconnect
Spare plug for mounting in installation box
For mounting in installation box
Set of two M12 sensor plugs for mounting in cable gland hole
Control card with 24 V backup
Control card Profibus with 24 V backup
Control card EtherNet with 24 V backup
Control card Profinet with 24 V backup
2 cable clamps
bracket for motor/loads cables
elevation bracket for cable clamp
screw 4 mm 20 mm
thread forming 3.5 mm 8 mm
MG04H102 - VLT
Decentral Drive FCD 302
®
is a registered Danfoss trademark
Ordering No.
130B5771
130B5772
130B5776
130B5778
130B5780
130B1078
175N2116
175N2703
130B5833
Ordering No.
130B5770
130B5773
130B5774
130B5775
130B5777
130B5779
130B5411
130b5783
130b5781
130b5788
130b5794
