APCI-3xxx
Accessories 1
For analog I/O:
Cable: ........................................................ - ST010
Screw terminal panel: ................................ - PX 901-AG
or connection box: ..................................... - PX-BNC
For digital I/O:
Cable: ........................................................ - FB 8001
Screw terminal panel: ................................ - PX8001
4.3

Limit values

Max. altitude: ............................................ 2000 m
Operating temperature: .............................. 0 to 60°C (with forced
Storage temperature: ................................. -25 to 70°C
Relative humidity at indoor installation
50% at +40 °C
80% at +31 °C
Minimum PC requirements:
Bus speed: ................................................. ≤ 33 MHz
Operating system:
Slots: .......................................................... 32-/64-bit PCI slot 3.3 V / 5 V
Not included in standard delivery.
1
:
NOTICE!
The connection lines must be installed in such a way
that they are protected against mechanical loads.

Fig. 4-1: Required slots

37x
- ST370-16
ventilation)
Windows 8/7/XP, Linux
+ 1 slot opening for the
connection of the TTL I/O or dig.
I/O
Technical data
