Technical description
4.3

Versions

The board is available in the following versions
PA358-4 with 4 voltage outputs PA358-4C
PA358-6 with 6 voltage outputs PA358-6C
PA358-8 with 8 voltage outputs PA358-8C
4.4

Limit values

Operating temperature: .............................................. 0 to 60°C
Storage temperature: .................................................. -20 to 80°C
Relative humidity: ..................................................... 80% non condensing
Minimum PC requirements:
ISA bus interface
Betriebssystem: .......................................................... MS DOS 3.3 oder höher
Bus speed: .................................................................. 8 MHz
Energy requirements:
Operating voltage: ..................................................... 5 V ± 5% / ± 12 V from the PC
Current consumption im mA (without load): ............ See table
5V
+12V
-12V
Analog output channels
Output voltage range: ................................................. 0-10 V; 0-5 V; ± 10 V, ± 5 V
Max. output current: ................................................... +5 mA / -5 mA
Maximal capacitive load: ........................................... 1000 pF
Settling time: .............................................................. 4 µs in unipolar mode
Resolution: ................................................................. 12-bit
Number of analog output channels: ........................... 4/6/8
Unipolar offset error: ................................................. +0,5 mV maximal
Bipolar zero error: ...................................................... ±10 mV maximal
Integral, relative linearity: ......................................... ± ½ LSB
Differential nonlinearity: ........................................... ± 1 LSB (monotonic)
Gain error: .................................................................. ± 0,15% (FSR)
Max. residual voltage for current output: .................. 6 V
Max. voltage for current feeding: .............................. 35 V
Max. load: .................................................................. < 800 R at 24 V
Chapter 4
VOLTAGE
PA 358-8 PA 358-6
230mA 220mA
50mA 38mA
50mA 38mA
CURRENT
0(4)-20mA current outputs
0(4)-20mA current outputs
0(4)-20mA current outputs
Windows 3.1, NT, 95, 98
PA 358-4 PA 358-8C PA 358-6C PA 358-4C
210mA 60mA
26mA 50mA
26mA 50mA
5 µs in bipolar mode
PA 358
with 4
with 6
with 8
60mA 60mA
38mA 26mA
38mA 26mA
5
