General Description Of The Board - Addi-Data APCI-3010 Technical Description

Definition of application
1.4

General description of the board

Characteristics
The board has up to 16 single-ended input channels or up to 8 differential
input channels for processing analog signals.
Characteristics
Analog inputs:
Single-ended (SE)
or differential (diff.)
Resolution
Optical isolation
Throughput
Analog outputs
Resolution
Optical isolation
Digital inputs/outputs 4 inputs
TTL inputs/outputs
Timer
Counter
Watchdog
Connection
Data exchange between the board APCI-3xxx board and the peripheral is to
occur through a shielded cable. The cable must be connected to the 37-pin
SUB-D connector of the board. Furthermore, there is a 50-pin male
connector for the connection of the TTL I/O available, which must be
connected to the ribbon cable.
The use of the board APCI-3xxx in combination with external screw
terminal or relay boards is to occur in a closed switch cabinet.
8
Table 1-1: Overview
APCI-3010 APCI-3016
Up to 16 (SE) Up to 16 (SE)
Up to 8 (diff.) Up to 8 (diff.)
12-bit 16-bit
Yes Yes
200 kHz 200 kHz
- -
- -
- -
4 inputs
4 outputs 4 outputs
24 24
3 3
3 3
1 1
APCI-3xxx
APCI-3110 APCI-3116
Up to 16 (SE) Up to 16 (SE)
Up to 8 (diff.) Up to 8 (diff.)
12-bit 16-bit
Yes Yes
200 kHz 200 kHz
4 4
12-bit 12-bit
Yes Yes
4 inputs 4 inputs
4 outputs 4 outputs
24 24
3 3
3 3
2 2
